11.2 Manual deactivation of touch screen
Tap the on/off button [8] to remove the touchscreen tabs from the display, the
camera image remains.
11.3 Channel selecting
Tap the camera image to change to full screen view, and again to return to quad
display.
11.4 Manual recording
! When the full image is displayed, the other 3 channels are deactivated (see
Camera Setup [54] "Camera On") / with audio recording) or...
when using the quad modus when using more than one camera, more than
one camera is activated (without audio recording): tap the recording symbol
[36], the recording starts and the record symbol flashes.
! Tap the record symbol again, to stop the recording. Otherwise the recording
will stop automatically after approx 2 minutes.

Menu Overview

[44]Connect to internet (only possible after Network connection) ("Charge Only? No Internet" - in this case the cameras
can be viewed via using the App through a local WiFi network)
[43]Choose camera view
• SCAN - Scan mode (all activated camera images are displayed in full screen in sequence with a 5 second interval)
• QUAD - Quad mode (all activated cameras are dislayed together)
• Cam1 / Cam2 / Cam3 / Cam4 - activated cameras can be individually displayed in full screen
[42]Volume - Clock alarm and loudspeaker volume setting (Audio from camera microphone only available when in full screen image)
Default setting 6/6
[41]Submenu
[46]Return to camera image
[47]Playing back recorded video ("Record List")
[48]System menu
• Tap Camera symbol "A" [49] to show recorded video for all cameras in the selected month
• Tap Camera symbol "1" to "4" [50] to show recorded video for the individual camera in the selected month
The days with recorded video are highlighted in green
Tap the green highlighted day to show the individual recordings in that day
Tap the desired time to play the video Tap the symbol "X" to delete the video, tap the „X " after the file symbol to delete all
recordings from the selected day.
[54] Camera Setup
• Pairing - Tap the camera chanel number to which a new camera should be paired, within the next 60
seconds press the pairing button [23] on the camera
• Camera On - when a camera is added to the system the camera will turn on automatically, this
is indicated by a tick symbol. Tap on the camera symbol to deactivate it, this will be indicated by an "X"
symbol.
• Brightness - Tap the camera symbol to be able to adjust the brightness between -2 and 2. Default
brightness is "0".
[56] Recorder Setup

• Motion detection

Off - not activated
Low - motion detection with low sensitivity, detection starts a 2 minute recording
High - motion detection with high sensitivity, detection starts a 2 minute recording
Default: all cameras on "low"
12. Menu
! Tap the tab [32] to open the menu.
! Tap the right hand tab [45] to close the menu
! When in the menu you can:
! tap the home button [51] to close the menu
! tap the return button [52] to return to the previous menu step
Note:
When the monitor is connected to the internet it is not possible to open the
submenu. In order to open the submenu, for example to be able to read the Device
ID or security code, remove the monitor from the docking station (the Device ID is
also printed on the label under the monitor stand [7]).
