EN
WARNING: Always stop the engine and disconnect the spark plug
wire from the spark plug.
Removing the bump head
■ Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.
■ Unlock the spool retainer as shown and remove the spool.
■ Remove the bump head from the drive connector.
■ Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.
■ Turn the connector clockwise to remove.
■ Remove the washer.
WARNING: When using the brushcutter blade, the grass defl ector
must be removed from the blade guard.
Installing the blade
■ Place the upper flange washer over the gear shaft with the
hollow side towards the gear head.
■ Centre the blade on the upper flange, making sure the blade
sits flat.
■ Install the cupped washer with the raised centre away from the
blade.
■ Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.
■ Replace the blade nut and tighten securely by turning clockwise.
CONVERTING FROM BRUSHCUTTER TO STRING
TRIMMER
WARNING: Always stop the engine and disconnect the spark plug
wire from the spark plug.
Removing the blade
■ Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.
■ Remove the blade nut, washers, and blade.
■ Attach the grass deflector to the blade deflector; align the 3
screws on the grass deflector to the screw holes on the blade
deflector.
■ Using the combination wrench supplied, tighten the two bolts
securely.
WARNING: When using the line trimmer bump head, the grass
defl ector must be attached to the blade guard.
Installing the bump head
■ Place the upper flange washer over the gear shaft with the
hollow side towards the gear head.
■ Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.
■ Place the bump head on the drive connector.
■ Tighten securely with wrench.
Assembly
