Bosch ISIO Notice Originale page 17

Shrub Shear
We declare under our sole responsibility that the product de-
scribed under "Technical data" is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/35/EU,
2014/30/EU, 2006/42/EC, 2000/14/EC including their
amendments and complies with the following standards:
EN 60745-1, EN 60745-2-15 (battery powered product),
EN 60335-1, EN 60335-2-29 (battery charger), EN 50581.
2000/14/EC: Guaranteed sound power level 82 dB(A).
Conformity assessment procedure according to Annex V.
Equipment category: 25
Sprayer
We declare under our sole responsibility that the product de-
scribed under "Technical data" is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/35/EU,
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards: EN 60745-1,
EN 60745 (battery powered product), EN 60335-1,
EN 60335-2-29 (battery charger), EN 50581.
Technical file (2006/42/EC, 2000/14/EC) at:
Bosch Lawn and Garden Ltd., PT-HG/ENS-PA2,
Stowmarket, Suffolk IP14 1EY, England
Henk Becker
Executive Vice President
Engineering
Robert Bosch Power Tools GmbH
70538 Stuttgart, GERMANY
Stuttgart, 01.01.2017
Mounting and Operation
Action
*Delivery Scope
Battery Charging
Attaching Tool/Detaching Tool
Switching On and Off
Fitting Telescopic handle
Removing Telescopic handle
Adjusting Handle Length
Setting for Edge Cutting/
Setting Handle Angle
Removing Wheels
Working Instruction Telescopic
handle
Troubleshooting
Bosch Power Tools
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
Figure Page
1 250
2 250
3 250
4 251
5 251
6 251
7 252
8 – 9 252
10 253
11 – 12 253
Action
Sprayer Application
Maintenance
Accessories
*Scope of delivery differs with product variant.
Cutting Hedges
Before cutting check the hedge for foreign objects e. g. wire
fences.
Application
To maintain control hold the machine properly by the handle.
Holding the machine incorrectly could result in injury.
After use replace the blade transport guard.
Telescopic handle
The telescopic handle can be used with the grass and shrub
shear attachment. Before using the handle with the shrub
shear attachment, the wheels should be detached.
Anti Blocking
If the blade stalls on a tough material, the load of the motor in-
creases. The intelligent micro-electronics senses this over-
load condition and repeatedly reverses the motor, in order to
prevent stalling and to cut the material through.
This audible reversing cut action continues for up to 3 s.
After cutting through, the garden product continues in its nor-
mal mode, or in case the overload condition continues the
blades automatically stop in the open position (e. g. in case a
piece of metal fence accidentally blocks the garden product).
Battery Charge-control Indication
The battery charge-control indicator indicates the charging
progress. During the charging process, the indicator flashes
green. When the battery charge-control indicator lights up
green continuously, the battery is fully charged.
The battery charge-control indicator indicates the charge
condition of the battery for a few seconds when the On/Off
switch is pressed through halfway of fully.
LED
Continuous lighting, green
Flashing light, green
Flashing light, red
Continuous lighting, red
English | 17
Figure Page
13 254
14 254
15 254
Capacity
35 – 100%
15 – 35%
5 – 15%
0 – 5%
F 016 L81 391 | (15.9.16)
