RF Rx SW868/SW915/SW917/SW922-4S
//
Montage- und Anschlussanleitung / Funkempfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur sans fil
Istruzioni di montaggio e collegamento / Ricevitore wireless
Instruções de montagem e instalação / Receptor de rádio frequência
Инструкция по монтажу и подключению / Радиоприемник сигнала
English
To get the maximum range: use the specified antennas. With other an-
tennas, the maximum range may differ.
N.B.
The electrical connection may only be carried out by authorised per-
sonnel. The wireless receiver must not be used in connection with
other devices whose direct or indirect purpose is to ensure life or
health, or whose operation may pose a threat to humans, animals or
material assets. Subject to technical modifications. Moreover, steute
does not assume any liability for recommendations made or implied by
this description. From this description new claims for guarantee, war-
ranty or liability cannot be derived beyond the general terms and con-
ditions of delivery.
Start-up
Requirements:
- Mount device on standard DIN rail.
- Connect cable for supply voltage 24 VDC.
- A maximum of 40 switches can be taught in parallel.
- The LEDs show the operating states. After switching on the receiver,
the orange LED 1 flashes if no switch has been taught in. If the or-
ange LED 1 does not flash, switches have already been taught in.
Select operation mode
There are nine different operation modes (see table). The relay func-
tions can be combined with the switching functions.
1. Keep the push-button LRN pressed and switch on the supply volt-
age, the operation mode changes every 5 s. For display of the LEDs,
see table. If LRN is not actuated within 5 s, it is switched to a
different operation mode.
2. If the desired operation mode is displayed, press the push-button
LRN for 1 s. The selected operation mode is active now.
Operation mode
LED 1
LED MD
Standard
flashes
flashes
fast
fast
Relay functions
Standard,
flashes
on
inverse output
fast
Relay energised
on
flashes
fast
Relay energised,
on
on
inverse output
Switch functions
Function
Relay energised by actua-
tion, relay and switch func-
tions are reset
Relay de-energised by actu-
ation, inverse output signal
Relay energised by providing
operating voltage
Relay energised by providing
operating voltage, inverse
output signal
4 / 24
Operation mode
LED 1
Linkage
flashes
slowly
Latching func-
on
tion
Wiping
flashes
function
slowly
Additional func-
tions
Battery moni-
off (LED
toring
3 flash-
es)
Status moni-
off (LED
toring
4 flash-
es)
Notice
If only one or both additional functions are activated, no further wire-
less transmitter can be taught in.
Operation mode wiping contact
- Choose or select wiping function. LED MD flashes.
- With each flashing of the LED, the wiping time is increased by 1 s.
- Count the impulses of the flashing LED and confirm the desired time
by pressing the LRN push-button.
- In order to change the wiping contact time, start selection of opera-
tion mode and select wiping function again.
Operation mode status monitoring
- After selection of status monitoring the LED MD flashes
every second.
- The LEDs 1-4 indicate the adjustable status times.
- The display of the LED changes every 5 s (see table).
- If the required LED combination is indicated, press the LRN push-
button for 1 s. The desired operation mode is now activated.
- Without confirmation of the selection, the standard value of 10 s
is set.
Status
LED 1
LED 2
signal time
10 s
on
off
100 s
on
on
1000 s
on
on
10000 s
on
on
LED MD
Function
on
Relay energised as soon as
one switch is actuated, de-
energises when all taught-in
switches are not actuated
flashes
Latching function/impulse
slowly
function
flashes
Wiping function, contact
slowly
automatically de-energises
after the set time
flashes
Relay K3 indicates under-
slowly
voltage of the taught-in and
battery-powered switches/
transmitters
flashes
Relay K4 indicates status
slowly
error; activates function only
in combination »switch with
status signal«
LED 3
LED 4
LED MD
off
off
flashes every s
off
off
flashes every s
on
off
flashes every s
on
on
flashes every s
