Line In 1 Line In 2
R2000DB
Multimedia Speaker
OPT
Input Indicator(LED)
RED OPT
GREEN Line In 1/Line In 2
BLUE
L Speaker Out
Power
Off On
1
2
3
4
5
6
7
8
Speaker In
9
① Master volume dial
Press in to cycle input sources:
Line in1/Line in2/
Optical/Bluetooth
② RCA connectors for AUX input
③ Optical input port
④ Treble dial
⑤ Bass dial
⑥ Connector to left (passive) speaker
⑦ Power cord
⑧ Power switch
⑨ Connector to right (active) speaker
⑩ Indicator light
Green: Line in1/ Line in2
Red: Optical
Blue: Bluetooth
Illustrations
