4. Keep your pressure pot clean and protect it from damage.
5. Depressurize after using.
SPECIFICATIONS - 5 Gallon Pressure Pot
Overall Dimensions: 32.68" H x 18.89" L x 11.42" W
Weight: 27 lbs
Hose Length: 8 Feet
AIR SUPPLY REQUIREMENTS
Working with pressure pots requires a large volume of air at high pressure. The efficiency of your
work can be adversely affected by the use of too small of an air supply hose, insufficient air pressure
or an overly large nozzle.
Hose Interior
Hose Length
Diameter
3/8"
50 ft
3/8"
25 ft
1/2"
50 ft
1/2"
25 ft
We recommend that air pressure in the range of 65-125 PSI.
ABRASIVE FLOW ADJUSTMENT
1. Choose a larger nozzle for a broader spray pattern. Choose a smaller nozzle for more focus.
2. Adjust air pressure with the air pressure adjuster (#9). Adjust media flow with media metering valve
(#26).
3. Watch for media clogging. Depressurize if necessary and replace the media with drier or cleaner
abrasive.
Nozzle Interior
Compressor
Diameter
Horsepower
0.076"
2
0.098"
4
0.118"
7
0.132"
10
- 7 -
CFM 125 PSI
MEDIA USE
PER HOUR
6
30 lbs
12
80 lbs
20
120 lbs
25
150 lbs
