Wall Mounting The Adapter; Mounting The Adapter - Bose SoundTouch Série II wireless adapter Notice D'utilisation

You can mount the wireless adapter on a wall (hardware not included). If your
mounting hardware comes with instructions that differ from these instructions,
follow the instructions supplied with your hardware.
This table describes mounting hardware specifications.
Item
Wall thickness
Drill bit
Pan-head wood screws (2)
Plastic wall anchors (2)

Mounting the adapter

There are two ways to mount the adapter:
• Vertically; connector panel facing left.
• Horizontally; connector panel facing up.
1. Drill two holes 6
2. Insert plastic wall anchors (if mounting to wallboard).
3. Install pan-head wood screws.
Note: Leave the screw heads
4. Position the adapter onto the screws and press firmly into place.
Wood
⁄ in. (19 mm) or thicker
3
4
⁄ in. (3.17 mm)
1
8
#8 x 1 ⁄
1
Not used
⁄ in. (159 mm) center-to-center.
1
4
⁄ in. (6.35 mm) above wall surface.
1
4

Wall Mounting the Adapter

in. (32 mm)
4
Wallboard
⁄ in. (9.5 mm) or thicker
3
8
⁄ in. (4.76 mm)
3
16
#8 x 1 ⁄ in. (32 mm)
1
4
#6 - 8 x 1 in. (25.4 mm)
