Ricatech RMC200 Mode D'emploi page 4

Power Source
1. Plug the small end of the supplied ADAPTOR into the 12V DC INPUT JACK on the back of the unit.
2. Insert the 2-pin plug of the AC ADAPTOR into an appropriate 230V AC Mains wall outlet socket.
Headphones Jack Operation
1 Connect headphones to the HEADPHONE JACK.
2 Adjust volume to the desired listening level.
NOTE: When using headphones, the
The sound from all speakers is cut off.
NOTE: Headphones not included with unit.
Turntable Operation
Turn the unit on by rotating the ON/OFF-VOLUME ROTARY KNOB located on the front panel to the ON position.
1 Set the FUNCTION SWITCH to PH. for PHONO mode.
2 Set the SPEED CONTROL SWITCH to desire speed (33 1/3,45 or 78 rpm). Place the record on the turntable.
3 Use the CUE LEVER to raise the tone arm off its rest. Pull the TONE ARM slightly to the right side until hear
the "click" sound to activate the turntable.
4 Move the tone arm over the record and use the cue lever to lower it to the point you want the record to start.
Adjust the ON/OFF-VOLUME ROTARY KNOB to the desired listening level.
5 At the end of the record, the TONE ARM will stop automatically. You must return it to the TONE ARM REST
by hand.
Accessory:ADAPTER FOR 45 RPM
This adaptor allows you to play 45 RPM records.
1 Place the 45 RPM adaptor over the spindle.
2 Gently place your 45 RPM record onto the turntable.
3 Follow the steps under turntable operation to play your record.
Cassette Operation
1 Set the FUNCTION SWITCH to TA. for CASSETTE mode.
2 Insert a prerecorded tape through the CASSETTE DOOR. Tape will slide into the cassette
mechanism and start playing.
3 Adjust the volume level by turning the VOLUME KNOB .
4 For fast forwarding, press the CASSETTE EJECT/F.F half way in. Pressing again,
will stop the fast forwarding and return the cassette to the playing mode.
5 To stop and eject the cassette, press the CASSETTE EJECT/F.F in completely.
6 When one side of the tape finishes playing, the cassette will automatically stop.
NOTE: Remove the tape from the unit when it is not in use or stopped.
Radio Operation
1 Set the FUNCTION SWITCH to RA. for RADIO mode.
2 Set the AM/FM BAND SWITCH to the desired band (AM or FM).
3 Select the desired radio station by rotating TUNING KNOB.
4 Adjust the ON/OFF-VOLUME ROTARY KNOB to the desired sound level.
Antenna
Antenna: for FM reception, the unit is provided with a FM WIRE ANTENNA , move the wire until the reception is
clear and with no interferences. For AM reception, the unit is provided with a directional build-in ferrite antenna.
Rotate the set to find the position in which the best reception is obtained. Do not connect the EXTERNAL FM
ANTENNA to any outside antenna
CD Operation
Playing A CD
1 Set the FUNCTION SWITCH to CD. for CD mode.
2 Press the OPEN/CLOSE BUTTON to open the CD DOOR . Place a disc in the tray with the labeled
side of the disc facing up.
3 Press the OPEN/CLOSE BUTTON again close the CD DOOR. The display will show ―— —― for a few
seconds, then the total number of tracks on the disc will be displayed.―00‖ will be shown when there is
no disc inside the unit.
4 Press the PLAY BUTTON to start playback. The PLAY INDICATOR will light up.
Headphone
sound to the unit speakers will be cut off.
Jack
