7.9 Procedure for mounting/demounting
alloy rims
i
On some alloy rims, the rim channel at the middle
of the rim is very shallow or there is no rim channel.
The figure below shows this:
i
The demounting process for the wheel and
demounting the top tire bead differ, since the hook
cannot catch a suitable position. Depending on the
situation, the operator needs to find best position,
i. e. where the resistance for the wheel is the lowest.
Robert Bosch GmbH
Operation | Start Line TCE 420 | 43
8. Inflation
Inflation can lead to hazardous situations.
The user must undertake the necessary
precautions to ensure safety.
¶
Wear hearing protection.
¶
Wear safety goggles.
¶
To protect the user from potential
danger during inflation, only inflate the tire
to a maximum 3.5 bar while the tire is on
the rim-chuck plate.
¶
Avoid any distractions while inflating.
Constantly observe the tire inflation
pressure on the pressure gauge to avoid
over-inflation.
¶
When inflating, avoid all distractions.
!
During operation, the noise may reach 85 dB(A), for
this reason, the operator must wear the appropriate
protective gear.
!
The TCE 420 is equipped with a pressure-limiting
valve, but if the condition of tire and rim is not good
or the operation is performed incorrect, there is still
the possibility of the tire bursting.
!
Do not exceed the maximum pressure specified by
the manufacturer.
During the inflation process, the operator should keep
away from the tire as far as possible.
¶
Carefully check if the size of the rim is same to the
size of the tire.
¶
Check the wear state of the tire or whether there is
damage or not.
¶
During the inflation process, frequently check the
pressure inside the tire.
¶
The max. inflation pressure is 3.5 bar, do not exceed
manufacturer's recommended pressure under any
circumstances.
¶
Keep hands and body away from the tire.
