˜ Scope of delivery
Unpack the product . Remove the transport locks .
Accessory needed: Pair of scissors (Fig . B)
After unpacking the product, check if all parts
are complete and in good condition . Remove all
packaging materials, including protective foils,
before use .
1x Motor unit (with lock cap and lock screws (x 4))
and pole (with knurled screw)
1x Base
1x Front grille (with lock screw and lock nut)
1x Rear grille
1x Blade
NOTE: Various removable components are
delivered pre-assembled (see "Description of
parts") .
˜ Description of parts
Before reading, unfold the page containing the
illustrations and familiarise yourself with all the
functions of the product .
Fig . A
*Lock cap
[ 1 ]
Blade
[ 2 ]
Groove
3 ] [
Rear grille
4 ] [
Handle
5 ] [
Motor shaft
6 ] [
Speed control knob (0, I, II, III)
[ 7 ]
Oscillation control knob
8 ] [
Motor unit
9 ] [
Power cord with power plug
10 ] [
*Screw and nut
[ 11 ]
*Knob (tilt adjustment)
[ 12 ]
Base
[ 13 ]
*Knurled screw
[ 14 ]
*Lock screws (M5 x 8 mm) (x 4) (rear grille)
15 ] [
Grille clips (x 4)
16 ] [
*Lock screw (M2 .5 x 10 mm) and lock nut
17 ] [
(grille)
Front grille
18 ] [
Hanging device
[ 19 ]
* pre-assembled
˜ Technical data
Input voltage: 220–240 V ~
Power consumption: 45 W
Description Symbol Value
Maximum fan
flow rate
Fan power input
Service value
Standby power
consumption
Fan sound power
level
Maximum air
velocity
Measurement
standard for IEC 60879:1986 (corr . 1992)
service value
Contact details OWIM GmbH & Co . KG
for obtaining Stiftsbergstraße 1
more information 74167 Neckarsulm
GERMANY
www .owim .com
, 50–60 Hz
~
Unit
F 59 .11 m /min
3
P 43 .4 W
SV 1 .36 (m /min)/W
3
P 0 .0 W
SB
L 59 .12 dB(A)
WA
C 3 .44 meters/sec
GB/IE/NI 7
