DISCHARGE
mA
V
TEST/CHECK CAPACITY CHARGE
This feature enables capacity measurement of the rechargeable battery.
After full recharge, the battery will be discharged. Capacity (in mAh or
mA) can only be monitored when the battery has been fully discharged.
mA
V
060 I.4 i 2.40
CHARGE
Low capacity could indicate end-of-life of the battery.
With the DISPLAY key the following can be viewed.
mA
V
CHARGE CHARGE
STAGE 1 :
060 I.4 i 2.40
CHARGE
The max. charging
mA
V
current of 1000mA
CHARGE CHARGE
has been selected by
mA V
the user.
DISCHARGE
STAGE 2 :
mA V
DISCHARGE
DISCHARGE
A discharging current
rated at 50% of
charging current is
applied,
i.e. 500mA.
STAGE 3 :
END OF
DISCHARGE
MODE
The available
I920
capacity of the
I920
battery appears.
mAh
i.e. 1920mAh.
CHARGE
mAh
TEST
CHARGE
TEST
STAGE 4 :
END OF TEST MODE/
m Ah
TRICKLE CHARGE
