<< Operating instructions SATA filter 244/264/284 >>
and impacts during usage.
• Assembly and disassembly
15. Spare parts [5]
Art.
Description
No.
6981 Pack of 5 quick coupling nipples
15511 Automatic condensate drain valve
22046 Pressure gauge 0-10 bar (0-145 psi)
22087 O-ring 60 x 2.5
22137 Insert
22152 O-ring 33 x 2.5
22160 Sintered filter for [A]
22319 Pressure gauge 0-10 bar (0-145 psi)
24521 Cyclone separator with O-ring
24554 Filter housing cpl. with condensate drain valve
24582 Intermediate adapter cpl. with O-ring
28514 O-ring 19 x 2
28506 O-ring 13 x 1.5
37622 Mounting bracket
68007 Hexagonal screw M 6 x 14
81810 Fine filter cartridge, cpl. with O-ring for [B]
85142 O-ring 30 x 1.5
85357 Pin spanner for filter housing
85373 Activated charcoal cartridge, cpl. with O-ring for [C]
142273 Mounting bracket
148239 Air outlet module [D], cpl. with pressure regulation valve, pres-
sure adjustment screw, pressure gauge and ball valve
171488 Manifold cpl. with connection nipples
171496 Pressure regulation valve cpl. with gauge
