7.1.1. Technical specifications for measures according to EC/EN61557-13 Class 2
➢ Reference guideline: IEC/EN61557-13, Class 2, ≤30A/m @ In: 3.5mA ÷ 600mA, Fn: 40Hz ÷ 1kHz
➢ NOTE1 → in the measurements according to IEC/EN61557-13 add the followed conditions to the
general specifications
➢ NOTE2 → conditions valid for 6mA, 60mA e 600mA ranges
Intrinsic accuracy or parameter
influencing the measurement
Position
Supply voltage
Temperature
Non-sinusoidal waveform
External magnetic field with
frequency from 15Hz to 400Hz
according to IEC61000-4-8
Load current
Surface current due to common
mode voltage
Frequency
Repeatability
7.1.2. Electrical specifications
Conversion type:
Sample rate:
Temperature coefficient:
7.1.3. Reference guidelines
Safety:
EMC:
Application:
Insulation:
Pollution level:
Measurement category:
7.1.4. General characteristics
Mechanical characteristics
Dimensions (L x W x H):
Weight (battery included):
Max. cable diameter:
Mechanical protection:
Power supply
Battery type:
Low battery indication:
Battery duration:
Auto Power OFF:
Communication interface
Bluetooth:
Display
Characteristics:
Over range indication:
Designation code
E1
E2
E3
E9
E11
E12
E13
E14
E15
TRMS
5 times / second
0.1x(accuracy) /°C, <18°C o >28°C
IEC/EN61010-1, IEC/EN61010-2-032
IEC/EN61326-1
IEC/EN61557-13, Class 2
double insulation
2
CAT III 600V
230 x 100 x 24mm (9 x 4 x 1in)
500g (18 ounces)
40mm (2in)
IP20
2x1.5V batteries type AA LR03
symbol "
approx. 60 hours
after 20 min of idleness
BLE 4.0 (max distance 10m)
4 LCD, 6000 counts, decimal point, and
backlight
"OL" message at display
EN - 12
Added specification
± 1%rdg
No error added
0.1 x (accuracy) /°C (<18°C o >28°C)
No error added
Add error ±10µA for 1µT (magnetic field)
Add error ±6µA for 1A (load current)
No error added
No error added
No error added
" at display
HT77C
