GROUPS When the ZONES/GROUPS option is selected in the DESTINATION field, use this field to select the specific group of au-
dio zones in which the alarm signal is to be transmitted. Use the + and - keys to select the name of the group of zones from
those previously defined using the GROUPS menu. If you choose the NO GROUP option (default selection), no group is se-
lected.
IMPORTANT NOTE
• To prevent errors during the compilation of the system configuration files, it is indispensable to select only an audio zo-
ne in the ZONE field, or a group of zones in the GROUP field, but not both. When the selection of a group of zones is
carried out, the NO ZONE option must always be selected in the ZONE field.
RELAY OPEN Used for choosing a relay of the IO 3250 digital INPUT/OUTPUT boards with normally open contact (OPEN), to be swit-
ched to closed with the activation of the alarm function. The relay is switched back to the normal position, defined using the
RELAY CONFIGURATION menu, as soon as the alarm function is disactivated. Use the + and - keys to select the name of
the desired relay from those defined using the RELAY CONFIGURATION menu (NAME field). If you choose the NO RELAY
option, no relay is selected.
RELAY CLOSED Used for choosing a relay of the IO 3250 digital INPUT/OUTPUT boards with normally closed contact ("CLOSED"), to be
switched to open with the activation of the alarm function. The relay is switched back to the normal position, defined using
the RELAY CONFIGURATION menu, as soon as the alarm function is disactivated. Use the + and - keys to select the na-
me of the desired relay from those defined using the RELAY CONFIGURATION menu (NAME field). If you choose the NO
RELAY option, no relay is selected.
The first screen only shows the first 3 fields of the submenu. To display the subsequent or previous fields, press the "↑ / ↓" and/or "pag↑ /
pag↓" keys.
EMERGENCY KEY DEFINITION
SOURCE
MESSAGE
PLAY MESS.
PLAY MESS.
DESTINATION
ZONE
GROUP
ZONE
GROUP
RELAY OPEN
RELAY CLOSE
To exit from the submenu, press ESC and proceed as described in the section EXIT FROM A MENU.
PROGRAMMING THE F1, F2, F3 KEYS
IMPORTANT NOTE
• It is not possible to program the F1, F2, F3 keys of a console if the DISABLE option is selected in the KEY F1, KEY F2, KEY F3 fields of
the CONSOLES menu.
To display the submenu used for programming the F1, F2, F3 keys of each console, move the selection point to the field of the key to be con-
figured (e.g. KEY F1), and press F3. The fields described below appear on the control unit display.
SPECIAL KEY DEFINITION
MESSAGE
RELAY N.O.
RELAY N.C.
MESSAGE This field is accessible only if the PLAY option is selected in the KEY F1, KEY F2 or KEY F3 field of the CONSOLES me-
nu. It is used for selecting the name of the audio file to be played. Use the + and - keys to select the name of the desi-
red audio signal from those present in the library of audio signals provided with the system, or those created by means of
the RECORD, ASSEMBLY and TONE GENERATOR functions (see the section USING THE "RECORDER" MENU). If you
select the NO MESS. option, no audio signal is selected.
RELAY N.O. This field is accessible only if the RELAY option is selected in the KEY F1, KEY F2 or KEY F3 field of the CONSOLES me-
nu. It is used for selecting a relay with normally open contact (N.A.) to be switched. Use the + and - keys to select the na-
me of the desired relay from those defined using the RELAY CONFIGURATION menu (NAME field). If you choose the NO
RELAY option, no relay is selected.
RELAY N.C. This field is accessible only if the RELAY option is selected in the KEY F1, KEY F2 or KEY F3 field of the CONSOLES me-
nu. It is used for selecting a relay with normally closed contact (N.C.) to be switched. Use the + and - keys to select the
name of the desired relay from those defined using the RELAY CONFIGURATION menu (NAME field). If you choose the NO
RELAY option, no relay is selected.
To exit from the submenu, press ESC and proceed as described in the section EXIT FROM A MENU.
PLAYBACK_ _ _ _ _ _ _ M
MSG 1_ _ _ _ _ _ _ _ _ _ M
CONTINOUS _ _ _ M
Pag ↓
CONTINOUS _ _ _ M
ALL ZONES_ _ _ _ _ _ _ M
NO ZONE _ _ _ _ _ _ _ _ M
NO GROUP _ _ _ _ _ _ _ M
Pag ↓
NO ZONE_ _ _ _ _ _ _ _ M
NO GROUP_ _ _ _ _ _ _ M
NO RELAY _ _ _ _ _ _ _ M
NO RELAY _ _ _ _ _ _ _ M
NO MESS. _ _ M
NO RELAY_ _ _ _ _ _ _ M
NO RELAY_ _ _ _ _ _ _ M
