The first screen only shows the first 3 relays. To display the subsequent or previous relays, press the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
N. NAME
1 RLY 1 _ _ _ _ _ _ _
2 RLY 2 _ _ _ _ _ _ _
3 RLY 3 _ _ _ _ _ _ _
N. NAME
4 RLY 4 _ _ _ _ _ _ _
5 RLY 5 _ _ _ _ _ _ _
6 RLY 6 _ _ _ _ _ _ _
To exit from the submenu, press ESC and proceed as described in the section EXIT FROM A MENU.

USING THE "CONSOLES" MENU

- - - = = = MAIN MENU = = = - - -
->GROUPS
->RELAY CONFIGURATION
->CONSOLES
This menu is used for programming the BM 3616 digital consoles. From the main configuration menu of the control unit, use the ↑ / ↓ and/or
pag↑ / pag↓ keys to move the selection point to the submenu CONSOLES and press ENTER. The fields described below appear on the con-
trol unit display.
CONS. Indicates the identification number of the BM 3616 digital console to be programmed. This number is set locally on the con-
sole by means of the address assignment procedure (see the installation and operation manual for the BM 3616 console).
NAME Used for defining the identification name of the console, which can be composed of a maximum of 16 alphanumerical cha-
racters. Use the + and - keys to select the alphanumerical characters in rotation, and confirm each character with ENTER.
The numerical characters can be selected directly on the numerical keypad.
PASSWORD Used for defining the password for blocking use of the console. The password can contain up to a maximum of 8 numerical
characters. The numerical characters available are those which can be selected among the first 8 numerical keys of the con-
sole; i.e. 1, 2, 3, 4, 5, 6, 7, 8.
Use the + and - keys to select the numerical characters in rotation, and confirm each character with ENTER. The characters
can be selected directly on the numerical keypad.
If no character is entered in the field, and 8 blank spaces are left, no password is defined.
IMPORTANT NOTES
• In order to not define any password, 8 blank spaces must be left.
• In assigning the password, keep the following limitations in mind:
a. It is not possible to insert blank spaces between two numerical characters of the password.
b. It is not possible to insert blank spaces before the numerical characters of the password.
The examples shown in the table below can provide further clarification on password definition.
Example 1
Example 2
Example 3
Example 4
Example 5
PRIORITY Used for defining the priority level of the console. Use the + and - keys to set the priority in the range from 2 to 7.
Level 2 is the highest priority level that can be associated to the console; level 7 is the lowest priority level (see the section
ORDER OF PRIORITY).
GEN CALL Used for enabling or disabling the GENERAL CALL key of the console, which is used for selecting all the zones and/or grou-
ps of zones associated with the numerical keys of the console (keys 1 to 16).
Use the + and - keys to select one of the following options:
• ENABLE - GENERAL CALL key enabled.
• DISABLED - GENERAL CALL disabled.
EMERGENCY Used for enabling or disabling the ALARM key of the console, which controls the EMERGENCY event (see the section EVENTS
CONTROLLED FROM THE BM 3616 DIGITAL CONSOLES). Use the + and - keys to select one of the following options:
• ENABLE - ALARM key enabled.
• DISABLED - ALARM key disabled.
If the alarm key is enabled, it must be programmed using the dedicated submenu, by pressing F2 (see the section ALARM
KEY PROGRAMMING).
STATUS
OPEN _ _ _ _ M
OPEN_ _ _ _ M
CLOSED _ _ M
Pag ↓
STATUS
OPEN_ _ _ _ M
OPEN _ _ _ _ M
CLOSED_ _ _ _ M
1st 2nd 3rd
Char. Char. Char.
1 2 Blank
Blank Blank Blank
1 2 3
Blank 1 2
1 Blank 2
PASSWORD
4th 5th 6th
Char. Char. Char.
Blank Blank Blank
Blank Blank Blank
4 5 6
3 Blank Blank
3 Blank Blank
90
7th 8th Validity
Char. Char.
Blank Blank Allowed
Blank Blank Allowed
7 8 Allowed
Blank Blank Not allowed
Blank Blank Not allowed
