SOURCE Used for selecting the type of source to be monitored. Use the + and - keys to select one of the following options:
• NO -
• INPUT -
• OUTPUT - Indicates the outputs of the OB 3230 AUDIO OUTPUT boards.
• ACU -
AUDIO INPUT Used when the MANUAL monitoring mode is selected, for choosing the input of the IB 3210 / IB 3280 AUDIO INPUT boards
to be monitored. Use the + and - keys to select the name of the input desired from those defined by means of the INPUT
PROCESSORS menu (NAME field). If you select the NO INPUT option (default selection), no input is selected.
AUDIO OUTPUT Used when the MANUAL monitoring mode is selected, for choosing the output of the OB 3230 AUDIO OUTPUT boards to
be monitored. Use the + and - keys to select the name of the output desired from those defined by means of the OUTPUT
PROCESSORS menu (NAME field). If you select the NO ZONE option (default selection), no output is selected.
ACU Used when the MANUAL monitoring mode is selected, for choosing the A.C.U. to be monitored. Use the + and - keys to
select the identification number of the desired A.C.U.. If you select the NO ACU option (default selection), no A.C.U. is se-
lected.
NOTE
• Each time the system is reconfigured (see the section STORING A CONFIGURATION), the configuration of the "monitor" function is lost, as
it is only temporary.

SPECIFICATIONS

CP 3100

Function
Microprocessor
Video board
Audio board
RS 232 serial ports
RS 485 serial ports
DCI synchronous serial port
Parallel port
Ventilation
Power supply / Max. absorption
Dimensions (lxhxd)
Weight

MB 3200

Function
Board slot standard
N° of boards that can be installed
Power supply
Dimensions (lxhxd)
Weight

IF 3260

Function
N° of fittings for boards with terminals
Connection boards that can be installed
in each fitting
Rack height
Indicates no source monitored.
Indicates the inputs of the IB 3210 / IB 3280 AUDIO INPUT boards.
Indicates the A.C.U.s (RB 3300 back-amplifier boards).
Control unit
High-speed
VGA
16 bit
2
2
1
1
Forced
230 Vac ± 5% - 50 Hz (115 Vac - 60 Hz on request) / 200 VA
483 x 132 x 368 mm
7.8 kg
Sub-rack for modular electronic boards
DIN
Four IB 3210 / IB 3280 AUDIO INPUT boards
Eight OB 3230 AUDIO OUTPUT boards or eight IO 3250 digital INPUT/OUTPUT boards
5 Vdc – 13.5 Vdc - 24 Vdc
483 x 176 x 304 mm
3.7 kg (without boards)
Rack connection panel
5 fittings
Alternatively: 3 connection boards with 12 terminals, or 2 connection boards with
20 terminals, or 1 connection board with 32 terminals.
6 units
