UEi Test Instruments DL579 Manuel D'instructions page 9

• Rotate Rotary Selector Dial to NCV position move the tip of the clamp meter
near voltage source.
• Non-Contact Voltage Detection is used to detect power with sensor located
in the tip of the clamp head, indicates positive response with both an
Audible and Visual alert.
• Do not use Non-contact voltage detector to determine if there is current on
the wire. Detection operation could be affected by socket design, insulation
thickness, type or other factors.
• Voltage indicator light may also light when voltage (>AC/DC 30V) is present
on the meter's input jack or from an external interference such as motors,
flashlights, etc.
Features:
On Voltage
Approx. 24V AC
Non-Contact Voltage
RANGE
AUTO
AUTO
True RMS
CLAMP METER
SELECT
DISCONNECT TEST LEADS
CATIV 300V
CATIII 600V
9
NCV Sensor in the tip.
MAX/MIN
INRUSH
TEMP
