The UEi LRA Inrush is programmed to properly capture the starting current
for compressor motors. Inrush current can be measured in any position of
the rotary selector Dial.
• Select the range capable of capturing the maximum value.
• Press the INRUSH button – INRUSH will now be shown on the screen.
• Activate the compressor and read value on the display.
• Press the INRUSH button to return to live readings.
LRA Inrush
RANGE
MAX/MIN
INRUSH
AUTO
AUTO
Hz
True RMS
CLAMP METER
SELECT
INRUSH
DISCONNECT TEST LEADS
TEMP
CATIV 300V
CATIII 600V
INRUSH
• Rotary selector Dial = any position
• Press INRUSH
• Readings show on upper display
18
