Operation
Please use as much cable as
needed. Leave the remaining
cable out of the pool.
You may turn on
the cleaner when it
reaches the floor.
3.6 m / 11.8 ft
Placement of the Power Supply
Place the power supply at least 3.6 meters / 11.8 feet from the pool and at least
12 cm above ground. CAUTION: The power supply is not water resistant;
it must not be exposed to water or to direct sunlight.
Press the plastic snap on the zip ties in order to release the floating cable. Use
as much cable as needed in the water.
Before placing the cleaner unit in the water
Make sure there are no people in the pool. Make sure that the filters are clean.
Make sure the pool conditions are met; (see "Operating Conditions").
Placing cleaner in the water
Unroll the floating cable. It is recommended to extend a length of cable that is
equal to the diagonal size of the pool plus an additional two meters. Smooth
out coils or twists in the cable. Connect the floating cable to the socket located
on the power supply. Roll extra cable, not in the pool, near the power supply.
Place the robotic cleaner in the pool. Let it sink to the bottom of the pool. Do not
start operation before the robotic cleaner is settled on the pool floor. CAUTION:
Operating the cleaner out of water may cause immediate and severe
12 cm / 4.7 inch
damage resulting in loss of warranty.
above ground
Starting the robotic cleaner Connect the power supply to the wall socket. The
on/off button will light up and the robotic cleaner will start its cleaning program.
If the power supply is already connected to the wall socket, the on/off button will
flash to indicate that the robotic cleaner is in standby mode. Press the On/Off
button in order to change the above mode (On to Off – standby, or vice versa).
NO SWIMMING
WHILE THE ROBOT
Note: if the full filter indication light (only available on some models) is ON make
IS IN THE POOL
sure to remove and clean the filter prior to putting the cleaner back in the pool.
F1 R | F1 RX ROBOTIC POOL CLEANER
3
