English
Reversing the Door Handles
Note: Not reversible on stainless steel door models.
Freezer:
(see fig. # 7a)
1. Remove screw cover from the handles.
2. Using a phillips head screwdriver, remove the inside screw and both the
screws at the bottom of the freezer door that holds the handle.
3. Install the handle on the opposite side.
4. Remove screw plugs.
5. Install the screws and the screw cover on their corresponding position.
Hole cover
fig. # 7a
Refrigerator:
1. Remove screw cover from the handle.
2. Using a phillips head screwdriver, remove the inside screw and both
screws from the top of the refrigerator door that holds the handle.
3. Install the handle on the opposite side.
4. Remove screw plugs.
5. Install the screws and screw covers to their corresponding position.
Front Grill Installation:
1. Snap into place as shown below.
11
Hole cover
Hole cover
fig. # 7
(see fig. # 7)
(see fig. # 7b)
Hole cover
fig. # 7b
