Manuels Connexes pour Grundig L54315B
Sommaire des Matières pour Grundig L54315B
- Page 1 Installation instructions Instructions d’installation Hinweise zur Installation Istruzioni di installazione Instruc iuni de instalare Montaj Talimatları L54315B - Sliding 4578346503_AD...
- Page 2 Adjusting the legs If your refrigerator is unbalanced: You can balance your refrigerator by turning the legs of it as illustrated in the figure. The corner where the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite direction.
- Page 3 min. 200 cm No wooden back wall 40 mm min. 200 cm The back wall of the wooden cabinet must be left open completely to kitchen wall in order to allow sufficient air circulation to cool down the condenser unit for energy efficiency. La paroi arrière du meuble en bois doit être laissée complètement ouverte contre le mur de la cuisine, afin de permettre une circulation d’air suffisante pour refroidir le produit.
- Page 4 200 cm 2 200 cm * If the subject parts are not included in the product you have purchased, then it is valid for other models (see page 4). * Si les pièces concernées ne sont pas incluses dans le produit que vous avez acheté, elles sont valables pour d'autres modèles (voir page 4).
- Page 5 Torx Wood Plastic Sheet Wood (PS) (1TW) * Spares included * Pièces incluses * Ersatzteile inklusive * Ricambi inclusi * Piese incluse * Dahil olan parçalar view 42 mm ≤ 17 mm Note: Installation step for 2, screws for connecting top plastic part should not be screwed very hard, because of moving the plastic part easily left or right side.
- Page 6 4 mm...
- Page 7 (1TW) 2,0 mm...
- Page 8 21 mm 2 mm 4 mm 2 mm 2 mm...
