3.2 Intended use
The product described is an electrically powered combihammer. It is designed for drilling in concrete,
masonry, wood and metal. The product can also be used for light to medium-duty chiseling on masonry and
surface finishing work on concrete.
▶ Operation is permissible only when connected to a power source providing a voltage and frequency in
compliance with the information given on the type identification plate.
3.3 Possible misuse
• This product is not suitable for working on hazardous materials.
• This product is not suitable for working in a damp environment.
3.4 ATC
The product is equipped with the ATC (Active Torque Control) quick-acting electronic cut-out.
If the accessory tool sticks or stalls, the product will suddenly pivot about its own axis in the opposite direction.
ATC detects this sudden pivoting movement of the product and switches the product off immediately.
For ATC to function correctly, the product must be free to pivot.
After an ATC cut-out, switch the product off and then on again.
3.5 Active Vibration Reduction
The tool is equipped with an Active Vibration Reduction (AVR) system which reduces vibration noticeably.
3.6 Motor protection system
The tool is equipped with a motor protection system. The system monitors current input and motor
temperature and thus prevents the tool from overheating.
If the motor is overloaded through application of excessive working pressure, the power tool's performance
drops noticeably or it may stall completely.
If the power tool stalls or slows significantly due to overloading, release the pressure applied to the tool and
then allow it to run under no load for approx. 30 seconds.
3.7 Items supplied
Rotary hammer, side handle, depth gauge, operating instructions.
You can find other system products approved for your product at your local Hilti Center or online at:
www.hilti.com
4 Technical data
4.1 Combihammer
For rated voltage, rated current, frequency and/or input power, refer to the country-specific type
identification plate.
If the device is powered by a generator or transformer, the generator or transformer's power output must be
at least twice the rated input power shown on the rating plate of the device. The operating voltage of the
transformer or generator must always be within +5 % and -15 % of the rated voltage of the device.
Product generation
Weight in accordance with EPTA procedure 01
Ø Hammer drill bits
Ø Drill bits for wood
Ø Drill bits for metal
*2069236*
2069236
TE 30-ATC/AVR
02
4.0 kg
4 mm ... 28 mm
3 mm ... 25 mm
3 mm ... 13 mm
