STEP 1 - ACCOUNT CREATION IN THE CORTEX PLATFORM
1.
Download the
Cortex KIOUR
must be enabled on the smartphone and the app must have access to Bluetooth in the location of the device as well.
2.
Create an account by tapping the Create Account tab. The registered email will receive notifications in case of updates or alarms and cannot be changed at a
later date. Only the password can be changed.
3.
When an account is created, an activation email is sent to the registered email and this link must be confirmed in order to go to the main page of the Cortex
platform. The link must be tapped from the smartphone to which the app was downloaded.
4.
When you access the main dashboard, no device will be listed and the indication No data to display will appear.
STEP 2 - CONNECTING THE IOTW GATEWAY TO WI-FI – PROVISIONING
1. Plug the refrigerator into the outlet. The gateway lamp blinks 2 times/second which means it is in Wi-Fi connection standby mode.
2. Tap
to find your device and to register the desired Wi-Fi network. The gateway details can be found on the label, which
can be found on the right interior wall of the refrigerator.
3. If the network cannot be found, tap
4. If the details are entered correctly, provisioning is completed successfully; Done pops up on the screen and clicking it takes you to the main dashboard.
If the network details are entered incorrectly, provisioning is completed unsuccessfully; Close pops up on the screen and clicking it takes you to the main dashboard.
The network details you just entered to gateway must be deleted and the Wi-Fi network registration procedure needs to be restarted. For more information refer to
paragraph
Removal of existing Wi-Fi network from gateway.
A once-off Wi-Fi connection is necessary and you will not be required to repeat the procedure, unless you want to change the gateway Wi-Fi network.
*If you are unable to connect due to your smartphone's incompatibility with the above method, refer to paragraph
2. CONNECTING THE REFRIGERATOR TO THE CORTEX IOT CLOUD PLATFORM
app on your smartphone and grant access. The smartphone connects to gateway via Bluetooth BLE , therefore, Bluetooth
at the top right repeatedly.
Symbols on Cortex platform
Help
Information
Gateway restart
Edit gateway settings
More details
List renewal
Open technical sheet
Data export
Search list
Maximise screen
Minimise screen
Alternative Wi-Fi
connection.
