PACKAGE CONTENTS
D
B
F
PART
DESCRIPTION
QUANTITY
A
Drawer Front
1
B
Left Drawer Panel
1
C
Right Drawer Panel
1
D
Drawer Back
1
E
Drawer Bottom
1
F
Slide
2
C
E
A
2
HARDWARE CONTENTS (shown not actual size)
AA
BB
CC
M6 x 10 mm
Cam Lock
Screw
Wood Dowel
Qty. 4
Qty. 4
Cam Bolt
Qty. 8
Qty. 4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
WARNING
• Do not allow children to climb or play in or around this product.
• To avoid damage, assemble the product on a sturdy, level and protective surface.
• Make sure all bolts/screws are tightly fastened before the unit is used.
• Check bolts/screws periodically and tighten them if necessary.
• Do not exceed the weight limit: 30 lbs.
• Place the heavier items in lower drawers.
CAUTION
• Use this unit for its intended purpose only.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly (not included): Phillips Screwdriver
This drawer is intended to be placed into Premium Wood Tower (Item #0339207, 0339208, sold
separately) or Ventilatd Wood Tower (Item #0339212, 0339213, sold separately) and is a
replacement for the drawer in Complete Closet Kit (Item #0339203, 0339204, sold separately).
DD
EE
FF
M3.5 x 12 mm
Drawer Handle
Wood Screw
M4 x 25 mm
Wood Screw
Qty. 6
Qty. 4
3
GG HH
Qty. 1
