CHARGING THE BATTERIES
NOTE
Charge the batteries when the warning light (3
or 4, Fig. B) turns on, or when finishing
cleaning.
Keeping the batteries charged make them last
longer.
CAUTION!
When the batteries are discharged, charge
them as soon as possible, as that condition
makes them last shorter.
Check for battery charge at least once a week.
WARNING!
When using lead (WET) batteries, charging the
batteries produces highly explosive hydrogen
gas. Charge the batteries in well-ventilated
areas and away from naked flames.
Do not smoke while charging the batteries.
Do not reinstall the recovery water tank until
the battery charging cycle is over.
WARNING!
When using lead (WET) batteries, be extremely
careful while charging the batteries as there
may be battery fluid leakages. The battery fluid
is corrosive. If it comes in contact with the skin
or eyes, rinse thoroughly with water and
consult a physician.
CAUTION!
Batteries must be charged indoors, in a dry
environment (damp free).
1.
For lead (WET) batteries only: Remove the recovery
water tank as shown in the Use chapter.
2.
Drive the machine indoors, in a dry environment (damp
free), to charge the batteries.
3.
For lead (WET) batteries only:
– Check the level of electrolyte inside the batteries; if
necessary, top up through the caps.
– Leave all the battery caps open for next charging.
– If necessary, clean the upper surface of the batteries.
4.
Charge the batteries according to the following
procedure.
5.
Connect the battery charger cable (21, Fig. C) to the
electrical mains (the mains voltage and frequency must
be the same as the battery charger corresponding
values: see the Battery Charger Manual).
Razor SV17 — 909 6309 000(1)2006-01
INSTRUCTIONS FOR USE
NOTE
When the battery charger is connected to the
electrical mains, all machine functions are
automatically cut off.
The green warning light (27, Fig. C) flashes
when the battery charger is charging the
batteries.
6.
When the green warning light (27, Fig. C) stays on, the
battery charging cycle is over.
7.
When the battery charging cycle is over, disconnect the
battery charger cable (21, Fig. C) from the electrical
mains and wind it round its housing on the machine.
8.
For lead (WET) batteries only:
– Reinstall the recovery water tank as shown in the
Use chapter.
– Check the level of electrolyte inside the batteries; if
necessary, top up through the caps.
– Close all the battery caps;
– If necessary, clean the upper surface of the batteries.
9.
Now the machine is ready to be used.
NOTE
For further information about the operation of
the battery charger (26, Fig. C), see the relevant
Manual.
FUSE CHECK/REPLACEMENT
1.
For machines without battery charger only
Disconnect the battery connector (29, Fig. C).
2.
For machines with battery charger only
Remove the recovery water tank as shown in the Use
chapter.
For machines with battery charger only
3.
Disconnect the negative battery terminals (10, Fig. J).
4.
Remove the screws (5, Fig. I) and pull out the electrical
component box cover (1).
5.
Check/replace the following fuses:
– Brush (40A) (2, Fig. I)
– Vacuum (40A) (3, Fig. I)
– Solenoid valve and electronic board (5A) (4 Fig. I).
6.
Assemble in the reverse order of disassembly.
13
