SCHEDULED MAINTENANCE TABLE
Operation
Squeegee cleaning
Brush cleaning
Tank and vacuum grid cleaning
Squeegee blade check and replacement
Solution filter cleaning
Battery charger
WET battery fluid level check
Screw and nut tightening check
Brush motor carbon brush check or replacement
Vacuum system motor carbon brush check or replacement
(1): And after the first 8 working hours
(2): This maintenance operation must be performed by KENT authorized Service Center.
SQUEEGEE CLEANING
NOTE
The squeegee must be clean and its blades must be in good conditions in order to get a good drying.
CAUTION!
It is advisable to use protective gloves when cleaning the squeegee because there may be cutting debris.
1.
Drive the machine on a level ground.
2.
Make sure that the switches (5 and 6, Fig. B) are turned to "0".
3.
Lower the squeegee by means of the lever (19, Fig. C).
4.
Disconnect the vacuum hose (22, Fig. C) from the squeegee.
5.
Loosen the handwheels (12, Fig. C) and remove the squeegee (11).
6.
Wash and clean the squeegee. In particular, clean the compartments (1, Fig. E) and the vacuum hole (2) from dirt and
debris.
7.
Check the front blade (3, Fig. E) and the rear blade (4) for integrity, cuts and tears; otherwise replace them (according to
the procedure shown in the next paragraph).
8.
Assemble in the reverse order of disassembly.
SQUEEGEE BLADE CHECK AND REPLACEMENT
1.
Clean the squeegee according to the procedure shown in the previous paragraph.
2.
Check that the edges of the front (5, Fig. E) and rear blades (12) lay down on the same level, along all their length;
otherwise adjust their height according to the following procedure:
– Remove the fixing springs (6) and adjust the front blade (3) and the rear blade (4).
– Reinstall the fixing springs on the properly adjusted front and rear blades.
3.
Check the front blade (3, Fig. E) and the rear blade (4) for integrity, cuts and tears; otherwise replace them according to
the following procedure. Check that the front corner (9) of the rear blade is not worn; otherwise, overturn the blade to
replace the worn corner with the other one (7), provided that it is not worn. If the other corner is worn too, replace the blade
according to the following procedure:
– Remove the fixing springs (6) and replace (or overturn) the rear blade (4).
– Reinstall the fixing springs on the properly adjusted front and rear blades.
4.
Reinstall the squeegee (11, Fig. C) and screw down the handwheels (12).
5.
Connect the vacuum hose (22, Fig. C) to the squeegee (11).
Razor SV17 — 909 6309 000(1)2006-01
INSTRUCTIONS FOR USE
Daily or after
using the
Weekly
machine
Every six
Yearly
months
(1)
(2)
(2)
11
