INSTRUCTIONS FOR USE
BEFORE START-UP
Squeegee installation
1.
Install the squeegee (11, Fig. C) and fix it by means of
the handwheels (12), then connect the vacuum hose
(22) to the squeegee.
Solution tank filling
2.
Fill the solution tank (5, Fig. J) with a solution suitable for
the work to be carried out.
Do not fill the solution tank completely, leave few inches
from the edge.
Always follow the dilution instructions on the label of the
chemical product used to prepare the solution.
The solution temperature must not exceed 104°F
(40°C).
CAUTION!
Use only low-foam and non-flammable liquid
detergents, intended for automatic scrubber
applications.
NOTE
Use either the brush (14, Fig. J) or the
pad-holder (15) according to the type of floor to
be cleaned.
Brush or pad-holder installation
3.
Insert the positioning pin (24, Fig. C) and deactivate the
transport/parking device (23b).
4.
Lift the brush/pad cover (10, Fig. C) by prying the
handlebar (2).
5.
Place the brush (14, Fig. J) or the pad-holder (15) under
the cover.
6.
Lower the cover (10, Fig. C) by means of the handlebar
(2).
7.
Hook the brush/pad-holder by pressing the brush/pad
switch (5, Fig. B) for a few seconds.
If the hooking operation is difficult, manually rotate the
brush/pad-holder counter-clockwise (Fig. K).
Adjustments
8.
Using the knob (3, Fig. C), adjust the handlebar (2) to the
most comfortable position.
8
MACHINE START AND STOP
Machine start
1.
Prepare the machine according to the procedure shown
in the previous paragraph.
2.
Lower the squeegee (11, Fig. C) by means of the lever
(19).
3.
Turn the solution flow control lever (4, Fig. C) to one of
the following positions, according to the type of cleaning
to be carried out:
– ECO system: When the lever (4) is in the "ECO"
position (5a), the machine works in a special
condition of programmed water "economy" usage;
as the water flow is set and constant, the machine
can work with a washing autonomy of 70-80 minutes
[0.08 gal/min (0.3 liters/min) average].
– Variable system: When the lever is turned to the left
(variable flow), it is possible to increase the capacity
up to 0.26 gal/min (1 liter/min).
During machine operation, it is not possible to close
completely the water flow to the brushes.
4.
While keeping one hand on the handlebar (2, Fig. C),
start the machine by turning the brush/pad switch and
the vacuum switch (5 and 6, Fig. B) to "I".
NOTE
If the green warning light (2, Fig. B) turns on,
the machine is ready to be used.
If the yellow or red warning light (3 or 4, Fig. B)
turns on, it is necessary to charge the batteries
(see the procedure in the Maintenance
chapter).
Machine stop
5.
Turn the brush/pad switch and the vacuum switch (5 and
6, Fig. B) to "0".
6.
Lift the squeegee by means of the lever (19, Fig. C).
7.
Insert the positioning pin (24, Fig. C) and lift the
brush/pad by activating the transport/parking device
(23a).
Razor SV17 — 909 6309 000(1)2006-01
