Functional Description and Specifications
Disconnect the plug from the power source before making any
!
assembly, adjustments or changing accessories. Such preventive safety
WARNING
measures reduce the risk of starting the tool accidentally.
INTAKE
AIR VENTS
EXHAUST
AIR VENTS
SHAFT LOCK
DEPTH GUIDE
LOCKING
SCREW
NOTE: For tool specifications refer to nameplate on your tool.
1/4/06 9:39 AM
Spiral Saw™
COLLET NUT
Page 6
FIG. 1
BUMP-OFF SLIDE
"ON/OFF" SWITCH
DEPTH GUIDE
BRACKET
LOCK LEVER
DEPTH
GUIDE
-6-
SOFT BAND
HANDLE
COLLAR
