Invacare 65109 Instructions De Montage, D'installation Et D'utilisation

Rollator Basket
Assembly, Installation and Operating Instructions
Model No. 65109
SAVE THESE INSTRUCTIONS
NOTE: For use on Rollite™ Rollator Model Nos 65100-JR, 65100R-JR and 68100.
NOTE: Check all parts for shipping damage. In case of damage, DO NOT use. Contact
Carrier/Invacare for further instructions.
To ensure the safe and proper installation of the Rollator Basket, these instructions
MUST be followed:
DO NOT install this equipment without first reading and understanding this
instruction sheet. If you are unable to understand the warnings, cautions and
instructions, contact a healthcare professional, dealer or technical personnel
if applicable, before attempting to install this equipment - otherwise, injury or
damage may occur.
DO NOT carry or place weight exceeding 10 pounds in the rollator basket
when attached to rollator.
NEVER use the rollator basket as a means of support.
When using the rollator in a stationary position, the hand brakes MUST be
locked.
Always test to see that the rollator and attachments are properly and
securely locked in place before using.
INSTALLING/REMOVING THE BASKET
NOTE: Refer to WARNINGS in the SAFETY SUMMARY in this instruction sheet.
1. Place the seat in the UP position.
2. Install basket between the side frames and the seat supports so the hooks are
secured onto the seat supports as shown in FIGURE 1.
NOTE: The front basket hooks must be placed between the front frame tube and seat
support rivet as shown in DETAIL "A" of FIGURE 1.
3. Grasp the handle and lower the seat, pushing DOWN until the seat supports
fully engage the side braces.
NOTE: It is necessary to lift the seat in order to place items into or take items out of the
basket.
4. To remove the basket, reverse STEPS 1 through 3.
For more information regarding Invacare products, parts, and services,
Rollator Basket
All manuals and user guides at all-guides.com
SAFETY SUMMARY
WARNING
please visit www.invacare.com
1
Part No 1124247
