Invacare 65851R Instructions De Montage, D'installation Et D'utilisation

Rollators
Assembly, Installation and Operating Instructions
NOTE: Check ALL parts for shipping damage. If shipping damage is noted, DO NOT use. Contact carrier/dealer for further instruction.
• DO NOT use this product or any available optional equipment without first completely reading and understanding these
instructions and any additional instructional material such as owner's manuals, service manuals or instruction sheets supplied
with this product or optional equipment. If you are unable to understand the warnings, cautions or instructions, contact a
healthcare professional, dealer or technical personnel before attempting to use this equipment - otherwise, injury or damage
may occur.
• Each individual should ALWAYS consult with their physician or therapist to determine proper adjustment and usage.
• DO NOT use the rollator as a wheelchair or transport device. Rollators are not intended to be propelled while seated.
• The brakes MUST be in the locked position before using the seat.
• A physical/occupational therapist should assist in the height adjustment of the rollator for maximum support and correct brake
activation.
• Care should be taken to ensure that all hand and height adjustments are secure, and that casters and moving objects are in
good working order before using this or any mobility aid.
• All wheels MUST be in contact with the floor at all times during use. This will ensure the rollator is properly balanced.
• When using the rollator in a stationary position, the hand brakes MUST be locked.
• ALWAYS observe the weight limit on the labeling of your product. Check that all labels are present and legible. Replace if
necessary.
• The rollator basket has a weight limitation of 11 lbs (5 kg). The pouch has a weight limitation of 10 lbs (5 kg). Items placed in
either the basket or the pouch should NOT protrude from the basket or pouch.
• If push handles are exposed to extreme temperature (above 100°F or below 32°F), high humidity and/or becomes wet, prior to
use, ensure hand grips DO NOT twist on rollator handle - otherwise damage or injury may occur.
• After installation and before use, ensure that all attaching hardware is tightened securely.
• DO NOT attempt to reach objects if you have to move forward in the seat. Reaching for these objects will cause a change to
the weight distribution of the rollator and may cause the rollator to tip, resulting in injury or damage.
• DO NOT hang anything from the frame of the rollator. Items should be placed in the basket or the pouch.
• The backrest should ALWAYS be in place and is NOT designed to support the total body weight of the user.
• Before attempting to reach objects or pick them up from the floor by reaching down between your knees, place feet securely
on the floor. Use EXTREME caution when reaching for any object.
• Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories
designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products.
Patient Height Specifications
NOTE: For models not listed, please check labeling on product.
Care and Maintenance
1. Verify operation of the brakes and have them adjusted if necessary. Contact your Invacare dealer for brake adjustment.
2. If hand grip is loose, DO NOT use. Contact your Invacare dealer.
3. Inspect wheels periodically for wear or damage.
4. Replace any broken, damaged or worn items immediately.
5. For the best service from your rollator, always use replacement parts from Invacare.
6. Periodically inspect the casters and caster stems for assembly tightness and verify that the wheels are free of hair, lint and other debris
that could interfere with free wheel operation.
Attaching the Basket and Pouch
NOTE: Not all rollator models offer each accessory described in this paragraph.
NOTE: For this procedure, refer to FIGURE 1.
Pouch
Attach the pouch (not shown) to the seat support tube with snaps.
Basket
Install the basket onto the front seat support tube so the hooks rest on the front tube or underneath the seat.
For more information regarding Invacare products, parts, and services, please visit www.invacare.com
Part No 1148077
SAVE THESE INSTRUCTIONS
WARNING
ACCESSORIES WARNING
MODEL PATIENT HEIGHT MIN. / MAX
65851R & 65851B
65650 & 65650R
65650BB & 65650BR
65651BB & 65651BR
65350GR
66550
1
5'6" - 6'3"
5'5" - 6'2"
5'5" - 6'2"
5'0" - 5'6"
5'1" - 5'6"
5'8" - 6'5"
Rollators
