Assist Rails
Assembly, Installation and Operating Instructions
Model No. 6632
SAVE THESE INSTRUCTIONS
NOTE: The 6632 Assist Rails are ONLY to be used with the following Invacare Beds: 5410LOW,
5410IVC, 5410, 5310IVC, 5310, 5307IVC, 5307 and VC5310.
NOTE: Check all parts for shipping damage before using. In case of damage, DO NOT use the
equipment. Contact the dealer/carrier for further instructions.
To ensure the safe and proper installation of the Assist Rails, these instructions MUST be
followed:
WARNINGS
DO NOT install or use this equipment without first reading and understanding
these instructions. If you are unable to understand the Warnings, Cautions or
Instructions, contact a healthcare professional, dealer or technical personnel before
attempting to install this equipment - otherwise, death, injury or property damage
may occur.
These assist rails are intended to prevent an individual from inadvertently rolling
out of bed. DO NOT use for restraint purposes.
ENTRAPMENT MAY OCCUR. Proper patient assessment and monitoring, and
proper maintenance and use of equipment is required to reduce the risk of
entrapment. Variations in bed rail dimensions, and mattress thickness, size or
density could increase the risk of entrapment. Visit the FDA website at
http://www.fda.gov to learn about the risks of entrapment. Review A Guide to Bed
Safety, published by the Hospital Bed Safety Workgroup, located at
www.invacare.com. Use the link located under each bed rail product entry to access
this bed safety guide.
Invacare products are specifically designed and manufactured for use in conjunction
with Invacare accessories. Accessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare products.
Although assist rails are not rated to any specific weight limitation, the assist rails
may become deformed or broken if excessive side pressure is exerted on the side
rails. The assist rails when used in the UP position, are designed to aid the user in
sitting up or entering/exiting the bed. The assist rails should not be used to support
the full weight of the user. DO NOT use the assist rails as push handles when
moving the bed.
After any adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely. Assist rails with dimensions different from the
original equipment supplied or specified by the bed manufacturer may not be
interchangeable and may result in entrapment or other injury.
Ensure adjustment pins are fully engaged before using the guard or assist positions.
For more information regarding Invacare products, parts, and services,
please visit www.invacare.com
1
Assist Rails
Part No 1130185
