PROMIX66/88 – 6-CHANNEL/8-CHANNEL PROFESSIONAL MIXER
1. Introduction & Features
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the PROMIX66/88! Please read the manual thoroughly before bringing this device into service.
If the device was damaged in transit, don't install or use it and contact your dealer.
2. Safety Instructions
Be very careful during the installation: touching live wires can cause life-threatening electroshocks.
Keep this device away from rain and moisture.
Unplug the mains lead before opening the housing.
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer
will not accept responsibility for any ensuing defects or problems.
• A qualified technician should install and service this device.
• Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the device
against damage by leaving it switched off until it has reached room temperature.
• Do not expose the device to liquids and make sure not to place any object containing liquid on top of the device.
• Note that damage caused by user modifications to the device is not covered by the warranty.
• Keep the device away from children and unauthorised users.
3. Description
MONO Input Channel (fig. 1)
1. MIC Input
Each mono input channel offers a balanced microphone input via the XLR connector and also features a
switchable +48V phantom power supply for condenser microphones. The XLR jack is configured for pin 1
(ground), pin 2 (positive (+)) and pin 3 (negative (-)).
2. LINE IN
The LINE input is designed to accept balanced or unbalanced line level signals such as those from keyboards,
drum machines or samplers. There is enough gain available on the line input to accept even lower level signals
such as those from an unbalanced microphone or guitar output. If a balanced signal is to be connected to the line
input, then a 1/4" TRS (stereo) phone plug should be wired for the tip (positive (+)), the ring (negative (-)) and the
sleeve (ground).
NOTE: Either the MIC or the LINE input of a given channel can be connected at one time. Never connect both
simultaneously to the same channel.
