Two-Wire Loop Power and Current Measurement
1. Insert the black test lead banana plug into the negative (COM) jack
and the red test lead banana plug into the positive (mV-mA) jack.
2. Set the function switch to the "Power/mA measure" position.
3. Press the "0~19.9mA" button for a 0.01mA display resolution
(max display is 19.99mA); press the "0~24mA" button for a 0.1mA
display resolution.
4. Open up the circuit that is going to be measured and connect the
red test probe and the black test probe securely in series with the
load in which the current is to be measured.
DC mV Source
1. Insert the black test lead banana plug into the negative (COM) jack
and the red test lead banana plug into the positive (mV-mA) jack.
2. Set the function switch to the "mV source" position.
3. Adjust the "CAL ADJUST" to generate voltage (mV) to match the
output display value.
Battery Replacement
When the batteries become exhausted or drop below the operating
voltage, "BAT" will appear in the left-hand side of the LCD display.
1. Disconnect the test leads from the meter.
2. Open the battery door by loosening the screw using a Phillips head
screwdriver.
3. Insert the battery into battery holder, observing the correct polarity.
4. Put the battery door back in place. Secure with the two screws.
