shark ION ROBOT RV700 NC Serie Guide D'utilisation page 3

CHARGING THE SHARK ION™ ROBOT
The Shark ION Robot has a pre-installed rechargeable battery. Battery must be fully charged
before first use. The power switch must be in the ON position in order to charge the battery.
CHARGE INDICATOR LIGHTS
!
Clean
Dock Max
!
The blue Charge Indicator Lights indicate how
Clean
much charge is remaining.
Dock Max
3 ft.
3 ft.
5 ft.
Place the Charging Dock on a level surface with its back against a wall, in a space without obstructions, that
can easily be accessed by your robot. Remove any objects that are closer than 3 feet (1 meter) from either
side of the base, or closer than 5 feet (1.52 meters) from the front of the base. Plug the Charging Cable into
a wall outlet.
IMPORTANT: Install the charging dock in a location that can be easily accessed by your robot. Always keep the dock
plugged in, or the robot may not be able to automatically return. The robot will beep when it is first connected to power
or when it starts charging on the dock.
s h a r kc l e a n . c o m
Full Charge Nearly Full Mid Charge Low Charge
No Charge
While the robot is charging, all three blue LED
lights will cycle. When charging is complete, all
three blue lights will illuminate steadily.
If all the battery indicator lights are off, then
either the power switch is turned OFF or there is
no charge remaining. Turn the power switch ON.
If all indicator lights remain off, then charge the
unit on the dock.
CHARGING DOCK
Full Charge Nearly Full Mid Charge Low Charge
Full Charge
The Power switch must be in the ON position in
order to charge the battery.
When the cleaning cycle is complete, or if the
battery is running low, the robot will automatically
return to the charging dock. If your robot doesn't
return to the dock, the battery charge may have
run out.
CHARGING THE SHARK ION™ ROBOT
CHARGING
If the robot has no charge and cannot return to
dock, place it on the dock manually.
s h a r kc l e a n . c o m
