INSTALL THIS PRODUCT ON
1-1/4" HITCH RECEIVERS
ONLY (CLASS II OR
GREATER).
• Do not install on 2" receivers.
• Do not use with a hitch-extender.
• Maximum capacity: 2 bicycles.
In addition, some undersized receivers
may not accept this product. If you do
not know the capabilities of your hitch
receiver, consult an automotive
professional.
REAR WHEEL TRAY
HITCH
SAFETY
CLIP
LOCK WASHER
AND
HITCH BOLT
IMPORTANT WARNING
I
T IS CRITICAL THAT ALL YAKIMA RACKS AND ACCESSORIES BE PROPERLY AND SECURELY ATTACHED TO YOUR VEHICLE
ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT
. Y
OTHERS
OU ARE RESPONSIBLE FOR SECURING THE RACKS AND ACCESSORIES TO YOUR CAR
,
TO USE
AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT
UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS SUPPLIED WITH YOUR YAKIMA PRODUCT PRIOR TO INSTALLATION OR USE
I
F YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS
NOT THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES
PROFESSIONAL INSTALLER SUCH AS A QUALIFIED GARAGE OR AUTO BODY SHOP
1033335B-1/12
All manuals and user guides at all-guides.com
HookUp
RATCHET
STRAP
BASE PIN
AND CLIP
,
AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR TO
(1-1/4" HITCH)
HOOK
RED
TRIGGER
BASE
RECOMMENDED TOOLS:
,
CHECKING THE ATTACHMENTS PRIOR
,
,
WEAR
AND DAMAGE
,
OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE
,
YOU SHOULD HAVE THE PRODUCT INSTALLED BY A
.
PIVOT ARM
TIRE WIRE
BIKE TRAY
HEX
WRENCH
TRAY
BOLTS
WASHERS
NUTS
3/4" (19 mm) wrench
17 mm wrench
. I
MPROPER
. T
,
HEREFORE
YOU MUST READ AND
Part #1033335 Rev.B
.
