Installation of mains plug

Due to the many types of mains plugs, no mains plug is supplied with the
IH 070/090. A qualified electrician must install a suitable mains plug. The
correct supply voltage is shown in section 2.2.
The wires should be connected as follows:
IH 070
Colour of IH 070 wire
yellow/green
brown
blue
IH 090
Colour of IH 090 wire
yellow/green
brown
blue
Connect the IH 090 to only two of the three phases. Verify that the correct
circuit breaker is installed. See section 2.2 for circuit breaker specifications.
© simatec ag
Mains supply terminal
green Protection earth (PE)
black Phase 1 (L1)
white Neutral (N)
Mains supply terminal
Protection earth (PE)
Phase 1 (L1)
Phase 2 (L2)
Induction Heater IH 070/090 27
