5.3 Typical arrangement
NOTE
The factory supplies only the heat pump. All other components, including a bypass if necessary, must be
provided by the user or the installer.
ATTENTION:
In order to heat the water in the pool (or hot tub), the filter pump must be running to
cause the water to circulate through the heat pump. The heat pump will not start up if
the water is not circulating.
5. 5. 5. Location Location Location
This arrangement is only an illustrative example.
and and and connection connection connection
