dirna Bergstrom Bycool Green Line SLIM FIT Diagnostic De Pannes page 27

SLIM FIT
VEHICLES WITH ORIGINAL POWER SUPPLY CABLING - Electrical layout
Take care not to invert polarities when connecting the unit to the power supply. If this were to happen,
the plate would not come on and the unit would not work.
Centrifugal
blower
2,6 Amp.
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Gr
R-B
Compressor
electronic
module
2 Compressor
All manuals and user guides at all-guides.com
IMPORTANT NOTE!
Electronic
module
Comsuption 30 mAmp.
Compressor
electronic
module
27
Return
air sensor
NTC 15KΩ a 25º
Original
wiring
2,9 Amp.
PWM.
Condenser
fan
1 Compressor
EN
®
