PACKAGE CONTENTS
C
A
B
E
D
HARDWARE CONTENTS (not shown actual size)
AA
BB
Touch-up Pen
Bolt
Lock Washer
x 1
x 8+1 extra
x 8+1 extra
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product.
WARNING
Do not stand on vanity. Use vanity on level ground. Base
vanity supports a maximum weight of 200 lbs. Exceeding
maximum weight limit will compromise the integrity of the
vanity structure and could cause the vanity to fail.
CAUTION
Do not hang from the vanity.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware
contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 15 minutes
Tools Required (not included): Silicone compound.
PART
DESCRIPTION
A
Vanity Top (preassembled)
B
Vanity Base
C
Backsplash
D
Front Feet
E
Back Feet
CC
DD
EE
Flat Washer
Wood Dowel
x 8+1 extra
x 8+1 extra
Maximum load 200 lb. (90.71 kg)
Maximum load 10 lb. (4.5 kg)
Maximum load 30 lb. (13.6 kg)
2
ASSEMBLY INSTRUCTIONS
Water Supply Lines and Drain Installation Guide
QUANTITY
1. Mark wall for vanity placement and note the location of the water
1
supply lines and drain on the back panel of vanity.
1
1
2
2
FF
2. Move vanity (B) into proper place against the wall.
Hex Wrench
x 1
3. Install faucet, drain and supply lines (none included) to vanity top (A)
according to the instructions supplied with those items.
1
2
B
3
3
A
