HOW TO SELECT THE TIMER HOW TO SELECT THE TIMER
2 types of Timer mode can be selected on the remote control.
- Daily Timer
- Weekly Timer
- Daily timer and weekly timer could not be set at the same time.
- Select one of these Timers for your convenience.
How to Change the Display
TIMER/CLOCK
MODE UP SELECT
Press
OFF/ON DOWN SET
CLOCK CANCEL
- Press once to change the display from CLOCK to Timer or vice-versa.
- Press for more than 4 seconds to change the display from Daily Timer to Weekly Timer or vice-versa.
Daily Timer Display
Lights up if Timer operation is selected
ON Timer
To automatically
switch "ON"
the unit
OFF Timer
To automatically switch "OFF" the unit
Weekly Timer Display
Lights up if Timer operation is selected
ON Timer
To automatically switch "ON" the unit
Day to be selected
WEEKLY TIMER SETTING WEEKLY TIMER SETTING
►How to Set Weekly Timer
- You can set the Timer for each day of the week (Monday to Sunday) with 6 programs per day.
- ON Timer can be set together with your desired temperature and this temperature will be used
continuously.
- Same timer program cannot be set in the same day.
- You may also select collective days with same timer setting.
- Promotes energy saving by allowing you to set up to 6 programs in any given day.
Day and Timer Set Up Method
MODE
1. Press Timer for 4 seconds to change display to weekly timer.
UP DOWN
2. Press Timer or to select your desired day.
SELECT
3. Press to confi rm your selection.
SELECT
4. "1" will be blinking, press to set program 1.
OFF/ON
5. Press Timer to select ON or OFF timer.
UP DOWN
6. Press Timer or to select your desired time.
If you want to set the timer together with your desired temperature, press
SET
7. Press to confi rm program 1. The selected day will be highlighted with
• After 2 seconds, the display will move to the next program. Repeat steps 4 to 7 to set programs 2 to 6.
• During timer setup, if no button is pressed within 30 seconds, or if the
that moment is confi rmed and timer setup is ended.
Check Current Timer Program
Perform the steps below to check the timer program for a particular day.
MODE
1. Press Timer to enter timer mode.
SELECT
2. Press to enter day setting.
UP DOWN
3. Press Timer or until your desired day is shown, press
UP DOWN
4. Press Timer or to check the set programs.
Modify Current Timer Program or Add New Timer Program
MODE
1. Press Timer to enter timer mode.
SELECT
2. Press to enter day setting.
UP
DOWN
3. Press Timer or until your desired day is shown.
4. Perform steps 4 to 7 of "Day and Timer Set Up Method" to modify existing timer program, or add any timer
program.
Time to be selected
(10 minutes step)
6 different programs can be set
in a day (1 ~ 6)
Indicates the selected day
Indicates the next timer operation day
Time to be selected
(10 minutes step)
OFF Timer
To automatically switch "OFF" the unit
5
to select the temperature.
TEMP
.
SET
button is pressed, the setting at
SELECT
to confi rm your selection.
7
DAILY TIMER SETTING DAILY TIMER SETTING
►How to Set Daily Timer
- You can set ON timer only or OFF timer only or both ON and OFF timer in a day.
1
Change Display
MODE
Press Timer to change the display to daily timer.
2
Press Timer to select ON or OFF timer.
OFF/ON
Example: To turn ON the unit at 09:00
OFF/ON
Press Timer to select ON timer.
UP DOWN
Press or to select the desired time, then press
CANCEL
Or press if you do not want any setting for ON Timer.
Example: To turn OFF the unit at 18:30
OFF/ON
Press Timer to select OFF timer.
UP DOWN
Press or to select the desired time, then press
CANCEL
Or press if you do not want any setting for OFF Timer.
Note:
• When ON timer is set, the unit may start early before the actual set time in order to achieve the
desired temperature on time.
• Timer operation is based on the clock set in the remote control and repeats daily once set.
For clock setting, please refer to Remote Control preparation.
• The timer closest to the current time will be activated fi rst.
• If timer is cancelled manually or due to power failure, you can restore the previous setting by
SET
pressing .
Final Display of Daily Timer:
TIMER TIMER
ON
OFF
Only ON Timer is selected. Only OFF Timer is selected.
The unit will automatically The unit will automatically
switch ON at 9:00. switch OFF at 18:30.
Cancel Current Timer Program
Perform the steps below to cancel the timer program for a particular day.
1 , 3
1. Press
TIMER/CLOCK
MODE UP SELECT
2. Press Timer
2
OFF/ON DOWN SET
3. Press
CLOCK CANCEL
4. Press Timer
4
For example, if you want to set:
A - Monday to Friday: Unit ON at 09:00 with 20°C (program 1) & unit OFF at 18:30 (program 2).
B - Only Wednesday: Add timer to turn OFF the unit at 12:30 (program 3) and turn ON the unit at 13:30
(program 4).
■ To set A (Monday to Friday – Collective day setting)
To set the time, please refer to steps 1 to 7 of "Day and Timer Set Up Method" on page 7.
Program 1 – select ON, set desired time to 9:00 and desired temperature to 20°C.
Program 2 – select OFF and set desired time to 18:30.
Program 3 ~ 6 – no timer program set, press
■ To set B (Wednesday – add new timer program)
MODE
1. Press Timer to enter timer mode.
SELECT
2. Press Timer to enter day setting.
UP DOWN
3. Press Timer or until "WED" is selected, press
4. Perform steps 4 to 7 of "Day and Timer Set Up Method" to add program 3 and program 4.
Note: Timer that has setting nearest to the current time and day will be activated first.
Disable & Enable Weekly Timer
MODE
• To disable weekly timer setting, press , then press
• To enable previous weekly timer setting, press
TROUBLESHOOTING TROUBLESHOOTING
The following symptoms occur when abnormality occurs during operation.
• The unit stops and operation LED OFF.
• OFF indicator does not shown on remote control display.
When abnormality occurs, use remote control to retrieve error code.
Ensure the operation LED is in OFF condition.
OFF
Indicator 1. Press for 5 seconds.
OFF / ON
Operation
2. Press
LED
TIMER/CLOCK
MODE UP SELECT
FAN SPEED
2
3. Press for 5 seconds to quit checking.
OFF/ON DOWN SET
AIR SWING
4. Reveal the error code to authorized dealer.
1 , 3
CLOCK CANCEL
CHECK
SET
to confi rm the selected time.
SET
to confi rm the selected time.
TIMER
ON
OFF
Both ON and OFF Timer are
selected.
SELECT
to enter day.
UP DOWN
or until your desired day is shown.
SELECT
to enter program setting.
UP DOWN
or until your desired day is shown.
CANCEL
Press to cancel the program, will disappear.
MODE
or wait 30 seconds to exit weekly timer.
SELECT
to confi rm your selection.
CANCEL
.
MODE SET
, then press .
UP DOWN
or . If error code and abnormality can be
identifi ed, the operation LED will be ON continuously, then jot
down the error code.
