2 Setting up the Doorbird IP Video door station

8. The IP address of the TekSIP server is entered under "SIP Domain". This is used as the SIP
server address for the Doorbird station and the YOUVI software.
9. Select "Yes" for "Use TCP Transport for Large SIP packets".
10. Check if "Automatic" is selected under Startup to start the service at every restart.
11. Select "Save".
12. Select the Play button to start the TekSIP server.
13. After you have entered the credentials into YOUVI and the Doorbird software, the subscri-
bers will show up under „Registrations". Under „Extensions" they are marked with a green
icon:
2 Setting up the Doorbird IP Video door station
Set up the door station using the enclosed Quickstart instructions.
For the DoorBird IP Video door station to be properly able to communicate with the PEAKnx
touch panel, the DoorBird device's SIP-settings must be adjusted accordingly. To do so, use the
Doorbird app or the browser.

2.1 Option 1: Entering the SIP data via the browser

1. Go to the following page in your browser:
your administrator username and password, which you can find on your "DIGITAL PASS-
PORT" document.
https://webadmin.doorbird.com and log in with
