- Page 1 LightRaise™ interactive projector...
- Page 2 1018488 Rev 06...
- Page 3 Your SMART product includes instructions for installation on reinforced metal and wood stud walls and certain masonry wall types only. If you’re installing your SMART product on other wall types, refer to your local building authority for instructions, recommendations and safe work practices. To prevent injury or property and product damage, use only the mounting hardware recommended for your LightRaise™...
- Page 4 Il prodotto SMART comprende istruzioni per l'installazione esclusivamente su pareti in metallo rinforzato e con montanti in legno e determinati tipi di parete in mattoni. Se si installa il prodotto SMART su altri tipi di parete, fare riferimento alle autorità edili locali per istruzioni, consigli e pratiche di lavoro sicure.
- Page 5 PT-BR de parede de alvenaria. Se você for instalar seu produto SMART em outros tipos de parede, consulte a autoridade de construção local para obter instruções, recomendações e práticas de trabalho seguras. Para evitar ferimentos ou danos ao produto ou à...
- Page 6 До складу комплекту продукту SMART входять інструкції з його монтажу на металеві або дерев'яні каркасні стіни, а також на цегляні стіни певного типу. Якщо необхідно здійснити монтаж продукту SMART на стіну іншого типу, слід звернутися до місцевих компетентних будівельних органів, щоб отримати відповідні інструкції, рекомендації та методики безпечного...
- Page 7 Whiteboard System User’s Guide smarttech.com/kb/170295 smarttech.com/kb/170259 smarttech.com/kb/160505 LightRaise™ 60wi interactive projector installation template *1018490* 150% 100% (Optical) 1018490 Rev 03 This product and/or use thereof covered by one or more of the following U.S. patents. www.smarttech.com/patents...
-
Page 8: Table Des Matières
smarttech.com/kb/160505 a (×6) M5 (#10) c (×6) b (×6) M5 (#10) M5 (#10) 16.1 kg (35.5 lb.) e (×6) d (×6) M5 (#10) M5 (#10) 5 mm ×2 10' (3 m) 120 min 1018488 Rev 06... - Page 9 > 2" (5 cm) minimum LightRaise™ interactive projector smarttech.com/kb/170259 smarttech.com/kb/160505 LightRaise™ SLR60wi SLR60wi2 interactive projector SLR60wi2-SMP installation template 1018490 Rev 04 *1018490* (Optical) (Optical) 150% 100% This product and/or use thereof covered by 5 cm one or more of the following U.S.
- Page 10 > 2" (5 cm) minimum LightRaise™ interactive projector smarttech.com/kb/170259 smarttech.com/kb/160505 LightRaise™ SLR60wi SLR60wi2 interactive projector SLR60wi2-SMP installation template *1018490* 1018490 Rev 04 150% 100% (Optical) (Optical) This product and/or use thereof covered by 5 cm one or more of the following U.S.
- Page 11 > 2" (5 cm) minimum X, Y, Z =? LightRaise™ interactive projector smarttech.com/kb/170259 smarttech.com/kb/160505 LightRaise™ SLR60wi SLR60wi2 interactive projector SLR60wi2-SMP installation template 150% 100% (Optical) (Optical) 1018490 Rev 04 *1018490* 5 cm This product and/or use thereof covered by one or more of the following U.S.
- Page 12 LightRaise™ surface evaluation guide 0 mm <10 mm <10 mm <10 mm <10 mm smarttech.com/kb/170426 <5 mm <5 mm <5 mm smarttech.com/support 1018488 Rev 06...
-
Page 13: B (×6)
max of D or D range (mm) 0–6 7–12 13–19 20–26 27–33 34–39 40–46 47–52 53–60 (whiteboard thickness) max (mm) (number of shims required) (number of spacers required) (indicator setting) Left Right Indicator Indicator HOME position Final Indicator Settings Date L and R indicators Left Right... -
Page 14: M5 (#10)
M5 (#10) M5 (#10) M5 (#10) smarttech.com/kb/160505 M5 (#10) M5 (#10) 1018488 Rev 06... - Page 15 max (mm) max (mm) max (mm) max of D 1 , D 2 or D 3 max of D 1 , D 2 or D 3 max of D 1 , D 2 or D 3 range range range max. min.
- Page 16 5 mm 1018488 Rev 06...
- Page 17 1018488 Rev 06...
- Page 18 1018488 Rev 06...
- Page 19 1018488 Rev 06...
- Page 20 SLR60wi2-SMP 1018488 Rev 06...
- Page 21 SLR60wi Composite Audio AC Power Composite Control (9V) Video Light Curtain Line Out HDMI Control DC 5V 2A Panel VGA Out VGA In Touch Service Line In Composite 3.5 mm 3.5 mm 3.5 mm RJ-45 Light Curtain RS-232 Video HDMI <=>...
- Page 22 SLR60wi2 3.5 mm 3.5 mm 3.5 mm AC Power Light curtain DC 5V 2A Composite Audio Network Control Service Audio Audio VGA In VGA Out HDMI video Composite HDMI RJ-45 video Light Curtain RS-232 16' (5 m) Input Input Menu Menu Hide Hide...
- Page 23 SLR60wi2-SMP 3.5 mm 3.5 mm 3.5 mm AC Power Light curtain DC 5V 2A Composite Audio Network Service Audio Control Audio VGA Out HDMI VGA In video Composite HDMI RJ-45 video Light Curtain RS-232 16' (5 m) GoWire Input Input Menu Menu Hide...
- Page 24 5 mm 1/2 " (12 mm) 1/2 " (12 mm) 5 mm 1018488 Rev 06...
- Page 25 1018488 Rev 06...
- Page 26 5 mm 5 mm 1018488 Rev 06...
- Page 27 > 2.5" (10 cm) LightRaise 60wi Interactive Projector User’s Guide smarttech.com/kb/170295 smarttech.com/kb/170295 1018488 Rev 06...
- Page 28 LightRaise™ interactive projectors User’s guide Scan the following QR code to read this guide on your smart phone or other mobile device or go to: onlinehelp.smarttech.com/english/mobile/projectors/60wi/index.htm smarttech.com/kb/170295 1018488 Rev 06...
- Page 29 LightRaise™ interactive projectors User’s guide Scan the following QR code to read this guide on your smart phone or other mobile device or go to: LightRaise™ onlinehelp.smarttech.com/english/mobile/projectors/60wi/index.htm interactive projectors User’s guide Scan the following QR code to read this guide on your smart phone or other mobile device or go to: onlinehelp.smarttech.com/english/mobile/projectors/60wi/index.htm...
- Page 30 Introduction Alignment Finish Touch Module alignment Introduction Alignment Finish You will be optimizing touch detection by adjusting the touch module so that it can see all corners of your markerboard/surface. In order to complete the touch module alignment process, you will: 1.
- Page 31 Introduction Alignment Finish Alignment Tool top side status LED battery door ON/OFF switch front side handle back side 1. Turn the switch ‘ON’. 2. To test the alignment tool, press the ‘front side’ against the markerboard surface. The ‘status LED’ should turn green.
- Page 32 Introduction Alignment Finish Introduction Alignment Finish Introduction Alignment Finish Introduction Alignment Finish Introduction Alignment Finish Introduction Alignment Finish If you’re unable to turn the dial, click the button Increments Full rotations Full rotations If you’re unable If you’re unable to turn the dial, to turn the dial, click the button...
- Page 33 Introduction Alignment Finish Finish Click the Finish button with the mouse to exit smarttech.com/kb/170426 Right Left Indicator Indicator HOME position Final Indicator Settings Date L and R indicators Left Right 2× 1018488 Rev 06...
- Page 34 10' (3 m) 1018488 Rev 06...
- Page 35 120 min 1018488 Rev 06...
- Page 36 © 2012–2013 SMART Technologies ULC. All rights reserved. LightRaise, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMART Technologoes ULC in the U.S. and/or other countries. All third-party products and company names may be trademarks of their respective owners.
