FLIgHt operatIon

trimming the copter
Already shortly before the copter takes off, you can recognize
whether it wants to turn or glide in a particular direction.
Model slips (drifts) or tilts to the right:
• Reduce the speed and push the trim slider of the roll-function of
the right remote control lever stepwise to the left.
• Push the gas-lever forward again and check whether the correc-
tion was sufficient, if necessary shift the trim further to the left.
• Repeat the process until the space taxi no longer shows a
tendency to drift to the right.
Model slips (drifts) forward:
• Reduce the speed and push the trim slider of the nick function
on the right remote control lever stepwise backwards.
• Push the pitch lever forward again and check whether this was
sufficient for correction, if necessary shift the trim further to the
left.
• Repeat the process until the space taxi no longer shows a
tendency to drift forwards.

expLanatIon oF controL anD FunctIonS

Correct the deviations from the vertical ascent with the trim knob
of the turn function.
Model slips (drifts) or
tilts to the left:
• Proceed as described above,
but push the trim slider of the
tail function stepwise to the right.
Model slips (drifts)
backwards:
• Proceed as described above,
but push the trim slider of the
nick function stepwise forward.
Calibration function: If the Copter always drifts to one side after
launching, place the model on a horizontal surface (table, floor) and
reconnect the 2.4 GHz signal. Set the expert mode switch to 100%!!
Then, with the Copter switched on, put the two control levers in
the specified position (illustrated) till the transmitter emits a signal
and the LEDs on the copter flash. The calibration procedure is now
complete.
