Thank you for purchasing the BC-838 PLUS preprogrammed and learning
universal remote control. Before you can use your new remote, you will need this
manual to set up your new BC-838 PLUS to operate the specific A/V home
entertainment and any infrared transmission equipment you wish to control.
CONTROLS UP TO 8 DEVICES
Your BC-838 PLUS is designed to let you use one remote to operate your Audio
and Video equipment; any device designed to be operated by an infrared signal.
Your BC-838 PLUS comes with wide range transmitter for maximum range and
is capable for High Frequency Signal. You can choose any combination of eight
devices you would like to operate.

LEARNING FEATURE

The BC-838 PLUS comes equipped with the unique "learning feature" (next to
the regular Set Up), which means that you can copy almost any function from
your original remote control onto your new BC-838 PLUS . This comes in handy,
when after having setup your BC-838 PLUS you may find some functions from
your original remote missing on your BC-838 PLUS keypad.
BATTERY INSTALLATION / CHANGE
1. On the back of the BC-838 PLUS ,
pull the battery compartment cover.
2. Insert two (2) AAA new Alkaline batteries.
3. Match the batteries to the (+) and (-) marks
inside the battery compartment.
4. Close the battery compartment.

CLOCK SET UP

The BC-838 PLUS provides you to view the current status of Weekday and
Clock. Simply follow below steps:
1. Press the [SET] key to for 3 seconds and the LCD will be shown CODE SETUP .
2. Press & release the [CH+] for three (3) times to view the CLOCK SET page.
3. Upon the LCD shown as CLOCK SET , press the [SET] key once.
4 The HOUR of LCD will be blinks, press the [CH+] or [CH-] key to select
desired HOUR.
5. Press the [SET] key once, the MINUTE of LCD will be blinks,
press the [CH+] or [CH-] key to select desired MINUTE.
6. Press the [SET] key once, the WEEKDAY of LCD will be blinks,
press the [CH+] or [CH-] key to select desired WEEKDAY.
7. Check the setting of Weekday and Clock, if it is OK then press the [SET] key
to confirm and LCD shown as SUCCESS .
Press the [SET] key to for
3 seconds
NOTE :
• Press the [SET] key to confirm and store the setting of weekday and clock.
• During the set up of HOUR or MINUTE or WEEKDAY, you can leave the set up
individually by pressing of the [ESC] key to escape and the LCD shown
as EXIT and back to normal operation mode.
• Press the [ESC] key for escape and the selected setting will not be stored.
SETTING UP BY DIRECT CODE
Example: To set up the BC-838 PLUS for your TV:
1. Make sure your TV is switched on (not on standby).
2. Press the [SET] key for 3 seconds and the LCD will be shown CODE SETUP .
3. Press & release the [SET] key and the LCD will be shown TV-001 page.
4. Press the [Device] key to select a desired mode (TV, VCR, SAT or
AUD, etc...). In this case is [TV] key.
5. Enter the 3-Digit TV code from the code list for your brand equipment.
* If you perform this procedure correctly, the LCD shown the code number
and then SUCCESS
Press & release the [CH+] key
for three (3) times
Press the [CH+] or [CH-] key to
select desired Hour / Minute /
Weekday
Press the [SET] key to confirm
