Technical description
6.1 Device versions
The PerfectCharge MCA battery chargers are available in different versions.
Your MAC battery charger can be used to charge batteries up to a specified battery
capacity (see chapter "Technical data" on page 31):
• MCA1215: suitable for charging one supply battery and one starter battery
• MCA1225, MCA1235: suitable for charging up to two supply batteries and one
starter battery
• MCA1250, MCA1280: suitable for charging up to three supply batteries
• MCA2415: suitable for charging up to two supply batteries
• MCA2425, MCA2440: suitable for charging up to three supply batteries
For the identification of your device, see the reference number on the type plate.
6.2

Connections and controls

I
NOTE
The version for continental Europe is depicted.
No. in
Explanation/function
fig. 1, page 3
1 Mains connection
2 LIN2 bus connection
3 TENMP/LIN1 bus connection
4 CN2 socket for Alarm and Fan
5 Status LED
6 DIP switch
7 Battery terminals (+)
8 Battery terminals (–)
9 Starter battery connection
(MCA1215, MCA1225, MCA1235 only)
