EN
• Uninstalling ISOFIX system
To disengage the seat from the vehicle ISOFIX anchors, press the ISOFIX
arms button (F)
3.2. Vehicle belt installation only
If your vehicle does not have ISOFIX anchors, follow the steps below:
1. Place the safety seat on the car seat.
2. Push the safety seat towards the back using a firm, constant pressure on
both sides until it rests firmly against the vehicle seat.
3. Pull the headrest height adjuster
until see the diagonal belt guide (C).
4. Insert the vehicle belt inside the diagonal belt guide
4. FASTENING THE CHILD IN THE SEAT
NOTICE
• Reclining position (Optional)
The seat can be installed with or without recline position. To recline the seat,
extract the reclining system
plastic pieces are fixed in the slots (fig. 4.2).
CAUTION! If you have already installed the seat in the vehicle and wish to
recline it, you must uninstall it first, adapt the recline position and follow
the steps in point "3. Seat installations" to install it again.
• Adjust the headrest height
A correctly adjusted headrest
belt is ideally positioned, offering the child the best possible protection.
The headrest should be adjusted so that a space equivalent to two fingers
remains between the headrest and the child's shoulders.
1. Pull the headrest height adjuster
time. This will unlock the headrest (fig. 4.3).
2. Now you will be able to move the headrest
When the adjuster is released the headrest will remain locked in the
chosen position.
3. Sit the child in the seat and check the height. Repeat the process until the
correct height is achieved.
20
to unlock them and slide them backward (fig. 3.5).
(A)
100-150 cm. From 4 years to
12 years approx. (16-36 Kg)
(G) and slide it forward (fig. 4.1) until the two
(B) ensures that the diagonal part of the safety
and move the headrest up (Fig. 3.3)
(C)
(A)
and the headrest
(B)
to the desired height.
(fig. 3.4).
(B)
at the same
