5.2 Inserting/changing the bandsaw blade
WARNING
Risk of damage An unsuitable or incorrectly fitted bandsaw blade can damage the
saw.
▶ Use only bandsaw blades that are suitable for this saw.
WARNING
Risk of injury by contact with the bandsaw blade.
▶ Wear protective gloves when fitting the bandsaw blade.
1. Slacken the 2 screws securing the blade cover and remove the cover.
2. Turn the side handle counterclockwise to unscrew it from the casing of the bandsaw.
3. Swivel the lever in the direction of rotation through its full 180 ° of travel.
Note
The side handle has to be removed to allow the lever to pivot.
4. Slip the bandsaw blade into the blade guides, one after the other. The back of the
blade must touch the bearings in the bottom of the blade guides.
5. Slip the bandsaw blade over both rollers, one after the other.
6. Swivel the lever in the direction of rotation through its full 180 ° of travel.
7. Check that the bandsaw blade tool is correctly guided over both rollers.
8. Reinstall the blade cover.
◁ Make sure that the cover is correctly seated.
9. Engage the threads of the side handle and turn it clockwise to screw it into the casing
of the bandsaw.
10.Check that the bandsaw blade is correctly seated by repeatedly switching the bandsaw
on and then off again.
5.3 Fitting the side handle
CAUTION
Risk of injury Loss of control over the bandsaw.
▶ Use the product only with the side handle fitted. Screw the side handle into the
corresponding tapped hole in the casing.
▶ Fit the side handle.
5.4 Inserting the battery
WARNING
Electrical hazard Risk of short-circuit.
▶ Before inserting the battery, check that the battery contacts and the contacts on
the saw are free of foreign matter.
