TURNING THE E-SCOOTER ON/OFF:
Long press the power button (B) to turn on the E-Scooter. The LCD screen will light up.
•
Long press the power button (B) to turn off the E-Scooter. The LCD screen will turn off.
•
TURNING THE LIGHTS ON/OFF
• Press the power button (B) shortly to activate or deactivate the headlight and the rear light.
The brake light will light always when you use the brake. The scooter is also equipped with
•
reflection or reflectors at the front, sides and rear.
STARTING TO RIDE
Slide the scooter with your foot for 1-2 meters and then press the accelerator (D) for driving.
•
• Release the accelerator (D) and use the brake (2) for braking.
Important: Braking distance will extend during wet weather.
To change directions, lean slightly to the left or right and turn the handlebars slightly.
•
When the screen is on, press the << and >> buttons (A-C) to adjust the speed according to 1st,
•
2nd and 3rd class.
1st class
max. speed up to 6 km/h (pedestrian mode)
max. speed up to 15 km/h
2nd class
3rd class max. speed up to 25 km/h
Cruise Control: When riding at a fixed speed for 6 seconds, Cruise Control is automatically
•
activated (you will hear a beep) and you can release the gas throttle. To cancel cruise control,
brake or press the gas throttle.
• Please use the kickstand to keep your E-Scooter upright while parked or not in use.
BELL
The Guardo Pursuit has a mechanical bell, you can ring to alert and warn the traffic around you.

SCREEN INFORMATION

1. 2. 3.
15
1
Mph
4.
Km/h
0 1 0 3 0
TRIP Mile
5.
ODO Km
7.

ADJUSTING THE BRAKE

• Use the hex wrench anticlockwise to release the plate screws on back wheel.
• Adjust the length of exposed tail: shorten for tightening and lengthen for loosing the brake.
• Lock the pressure plate screws by rotating clockwise.
Note: Brake cables that are too loose will make it harder to brake. Test the tightness of your cables
by pulling each brake lever. If the levers hit the handlebars when you pull them, the brake cables
are too loose. Loosen the barrel adjusters, located where the brake cables meet the brake levers, for
minor brake cable adjustments. If the brake cable is still too loose, please contact your local reseller
for a qualified maintenance shop.
1.
Cruise Control ON
Alarm notification
2.
3. Front light ON
6.
4.
Selected speed class
5. Odometer: total riding distance
6. Actual speed
7. Battery status
