Operation

Keep the hand unit and the batteries dry and protect them from direct sunlight.
The camera cable and camera head are waterproof when mounted correctly. However,
the hand unit and the batteries are not protected against water. If they come into con-
tact with water, there is a risk of electric shock or damage.
Do not subject the inspection camera to extreme temperatures or variations in
temperature. As an example, do not leave it in vehicles for longer periods. In case of
large variations in temperature, allow the inspection camera to adjust to the ambient
temperature before putting it into operation.
Do not use the inspection camera when the lens on the camera head is misty or
fogged-up. Do not switch the inspection camera on until after the moisture has
evaporated. Otherwise, the inspection camera can become damaged.
The switched-on illumination light can become hot during operation. In order to
prevent burns, do not touch the illumination light.
3.4

Commissioning

Switching On and Off:
To switch on the inspection camera, press the On/Off button
on the display for a short time.
To switch off the inspection camera, press the On/Off button
If no button is pressed on the inspection camera for approx. 20 mins, it will automatically switch off to
save the batteries.
Regulating the Illumination Light in the Camera Head:
To brighten the camera image, you can switch on the illumination light in the camera head and adjust
the brightness.
The brightness can be adjusted in 6 stages.
To switch on the camera illumination light and to increase the brightness, press button
edly until the required brightness is reached.
Do not stare into the illumination light and do not direct it at other persons!
The brightness of the light can blind the eyes.
To reduce the brightness and to switch off the camera illumination light, press button
ly until the required brightness is reached or the illumination light is switched off.
Magnifying the Image on the Display (Zoom):
Briefly pressing button
Status Bar:
The status bar is shown on the display for approx. 2 seconds after every button press. It shows:
– the selected magnification
– the selected brightness
– the charging condition of the batteries
– the storage capacity (max 30 pictures)
3.5

Working Advice

Check the area that you want to inspect and pay particular attention to obstructions or hazard areas.
Bend the camera cable in such a manner that the camera head can be easily inserted into the area
subject to the inspection.
Carefully guide the camera cable in.
Adjust the brightness of the illumination light so that the image can be seen well. For heavily reflect-
ing objects, as an example, less light will provide a better image.
When objects to be inspected are represented unsharp, reduce or increase the distance between
camera head and object.
10
magnifies the image on the display (1.0x, 1.5x, 2.0x).
