Technical Data

Part Number (basic unit) .............................. 1500002878
Batterietyp ................................................... 4 x 1,5V LR6 (AA)
Operating time, approx. ............................... 3,5 h
Rated voltage .............................................. 6 V
Operating temperature ................................ 0° C - 50° C
Storage temperature .................................... -20° C - 60° C
Relative humidity ......................................... 95% RH non-condensing
Display resolution ........................................ 320x240 RGB with LED backlight (2.5-inch Color)
Smallest bending radius of camera cable .... 25 mm
Diameter of camera head. ........................... 8,5 mm
Dimensions (L x W x H) ............................... 152 x 90 x 40 mm
3

Function of the Unit

3.1 Overview
Hand unit
1
Camera cable
2
Camera head
3
Battery lid
4
Pull-out battery compartment
5
Mirror
6
3.2

Assembly

Inserting/Replacing the Batteries:
To open the battery lid, press the latch and fold open the battery lid.
Pull out the battery compartment and insert the batteries. When inserting, pay attention to the
correct polarity according to the representation on the inside of the battery compartment.
Slide the battery compartment all the way in and close the battery lid.
The symbol will appear on the display if the charging condition of the batteries is low. When the
battery symbol is empty, you have to replace the batteries because inspections are no longer possi-
ble.
Always replace all batteries at the same time. Only use batteries from one brand and with the identi-
cal capacity.
Remove the batteries from the inspection camera when not using it for a prolonged period of
time. The batteries can corrode and self-discharge during prolonged storage.
Mounting the Mirror, Magnet:
The mirror and the magnet can be mounted to the camera head as auxiliary aids.
Slide one of the auxiliary aids to the stop onto the recess on the camera head as shown in the
figure.
The magnet is only suitable for moving and removing loose, small and light objects.
Magnet
7
Status bar
8
Selected lighting/brightness
9
Storage capacity
10
Selected magnification
11
Battery indicator
12
ENGLISH
(A)
